Cylinder. crankcase 2 Diagram Yamaha F20 M(E/T/H)S/L
- Year
- 2001
- Model
- F20A
- Model code
- 65W
- Year
- 2001
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Power
- 20
- Sales region
- Finland (040)
- Colour
- Dark Bluish Gray Metallic 2 (DBNM2; 004D)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
65W-W009A-13-4D Cylinder Head Complete |
65W-W009A-13-4D |
US $1,856.56 |
||
| replacement | |||||
|
01
|
01
65W-W009A-16-1S Cylinder Head Complete |
65W-W009A-16-1S |
from US $1,829.26 |
||
|
02
|
02
65W-11111-02-94 Head, Cylinder 1For std |
65W-11111-02-94 |
US $1,356.93 |
||
| replacement | |||||
|
02
|
02
65W-11111-20-1S Head, Cylinder 1For std |
65W-11111-20-1S |
US $1,356.93 |
||
|
02
|
02
65W-11111-12-94 Head, Cylinder 1Ecm"f25a only" |
65W-11111-12-94 |
US $1,406.07 |
||
|
03
|
03
62Y-11133-10-00 Guide, Valve 1 |
62Y-11133-10-00 |
US $12.61 |
||
| replacements | |||||
|
03
|
03
62Y-11133-30-00 Guide, Intake Valve |
62Y-11133-30-00 |
US $12.61 |
||
|
03
|
03
62Y-11133-31-00 Guide, Valve 1 |
62Y-11133-31-00 |
from US $13.31 |
||
|
04
|
04
93450-09M01-00 Circlip |
93450-09M01-00 |
from US $1.49 |
||
|
05
|
05
62Y-11325-00-00 Anode |
62Y-11325-00-00 |
from US $8.60 |
||
|
06
|
06
66M-11328-00-00 Grommet, Anode |
66M-11328-00-00 |
US $1.94 |
||
|
07
|
07
66M-11327-00-94 Cover, Anode |
66M-11327-00-94 |
from US $5.24 |
||
|
08
|
08
66M-12535-00-00 Plate |
66M-12535-00-00 |
from US $3.54 |
||
|
09
|
09
97095-05012-00 Bolt |
97095-05012-00 |
from US $1.55 |
||
|
10
|
10
929-95056-00-00
Washer, Plate
|
929-95056-00-00 |
— | ||
| replacement | |||||
|
10
|
10
92990-05600-00 Washer, Plate |
92990-05600-00 |
from US $1.07 |
||
|
11
|
11
97013-06020-00 Bolt |
97013-06020-00 |
from US $1.42 |
||
|
12
|
12
929-03066-00-00
Washer, Plate
|
929-03066-00-00 |
— | ||
| replacement | |||||
|
12
|
12
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.39 |
||
|
13
|
13
904-30060-14-00 Gasket (Copper washer) |
904-30060-14-00 |
from US $1.39 |
||
|
14
|
14
90109-06M65-00 Bolt |
90109-06M65-00 |
from US $22.67 |
||
|
15
|
15
65W-11181-10-00 Gasket, Cylinder Head 1 |
65W-11181-10-00 |
US $79.72 |
||
| replacement | |||||
|
15
|
15
65W-11181-30-00 Gasket, Cylinder Head 1 |
65W-11181-30-00 |
from US $63.96 |
||
|
16
|
16
99530-08012-00 Pin, Dowel |
99530-08012-00 |
from US $1.18 |
||
|
17
|
17
90119-09M00-00 Bolt, With Washer |
90119-09M00-00 |
from US $8.19 |
||
|
18
|
18
97013-06025-00 Bolt |
97013-06025-00 |
from US $1.48 |
||
|
19
|
19
929-03066-00-00
Washer, Plate
|
929-03066-00-00 |
— | ||
| replacement | |||||
|
19
|
19
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.39 |
||
|
20
|
20
65W-11191-00-94 Cover, Cylinder Head 1 |
65W-11191-00-94 |
US $96.09 |
||
| replacement | |||||
|
20
|
20
65W-11191-00-1S
Cover, Cylinder Head 1
|
65W-11191-00-1S |
— | ||
|
21
|
21
65W-11356-00-00 Seal, Cylinder 2 |
65W-11356-00-00 |
from US $27.43 |
||
|
22
|
22
97013-06020-00 Bolt |
97013-06020-00 |
from US $1.42 |
||
|
23
|
23
929-03066-00-00
Washer, Plate
|
929-03066-00-00 |
— | ||
| replacement | |||||
|
23
|
23
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.39 |
||
|
24
|
24
97095-08014-00 BoltEcm"f25a only" |
97095-08014-00 |
US $1.07 |
||
| replacements | |||||
|
24
|
24
97D95-08014-00 Bolt, Hexagon Deep REcm"f25a only" |
97D95-08014-00 |
from US $1.07 |
||
|
24
|
24
97D95-08014-00 Bolt, Hexagon Deep REcm"f25a only" |
97D95-08014-00 |
from US $1.07 |
||
|
25
|
25
90430-08143-00 GasketEcm"f25a only" |
90430-08143-00 |
from US $1.81 |
||
|
26
|
26
6G8-15363-00-00 Plug, Oil |
6G8-15363-00-00 |
from US $8.05 |
||
|
27
|
27
932-1024M-79-00
O-Ring
|
932-1024M-79-00 |
— | ||
| replacements | |||||
|
27
|
27
932-10242-35-00 O-Ring |
932-10242-35-00 |
from US $3.04 |
||
|
27
|
27
93210-24800-00 O-Ring |
93210-24800-00 |
from US $2.29 |
||
|
28
|
28
94701-00375-00 Plug, Spark (Ngk Dpr6Ea-9) |
94701-00375-00 |
US $8.42 |
||
| replacement | |||||
|
28
|
28
DPR-6EA90-00-00 Plug, Spark (Ngk Dpr6Eb) |
DPR-6EA90-00-00 |
US $68.90 |
||
