Capsulevacuum distributor Diagram Yamaha F225 ETX
- Year
- 2005
- Model
- F225A
- Model code
- 69J
- Year
- 2005
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Power
- 225
- Sales region
- Japan (999)
- Colour
- Dark Bluish Gray 1 (DBN1; 008D)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
69J-42154-00-00 Lever, Throttle Controlレバースロツトルコントロール; |
69J-42154-00-00 |
from US $51.26 |
||
|
2
|
2
68V-42171-00-00 Bushing |
68V-42171-00-00 |
from US $5.24 |
||
|
3
|
3
90386-10001-00 Bush |
90386-10001-00 |
from US $1.36 |
||
|
4
|
4
90202-10002-00 Washer, Plateワツシヤ，プレート; |
90202-10002-00 |
from US $1.98 |
||
|
5
|
5
93410-10082-00 Circlipサークリツプ; |
93410-10082-00 |
from US $2.69 |
||
|
6
|
6
69J-42152-00-94 Gear |
69J-42152-00-94 |
from US $25.36 |
||
|
7
|
7
91690-30025-00 Pin, Spring |
91690-30025-00 |
from US $2.36 |
||
|
8
|
8
91690-30018-00 Pin, Spring |
91690-30018-00 |
from US $1.70 |
||
|
9
|
9
69J-42153-00-00 Shaft, Throttle Controlシヤフト，スロツトルコントロール; |
69J-42153-00-00 |
from US $30.84 |
||
|
10
|
10
69J-41632-00-94 Lever, Magneto Controlレバー，マグネツトコントロール; |
69J-41632-00-94 |
from US $27.06 |
||
|
11
|
11
663-85518-00-00 Joint, Ballジヨイント，ボール; |
663-85518-00-00 |
from US $8.64 |
||
|
12
|
12
90201-10M02-00 Washer, Plateワツシヤ，プレート; |
90201-10M02-00 |
from US $1.98 |
||
|
13
|
13
6E5-48344-00-00 Cable End, Remote Controlケーブルエンド，リモートコントロール; |
6E5-48344-00-00 |
from US $3.72 |
||
|
14
|
14
90468-18008-00 Clip |
90468-18008-00 |
from US $1.70 |
||
|
15
|
15
69J-41661-00-94 Bracket |
69J-41661-00-94 |
from US $131.11 |
||
|
16
|
16
97095-06045-00 Boltボルト; |
97095-06045-00 |
from US $3.04 |
||
| replacement | |||||
|
16
|
16
970-80060-45-00 Boltボルト; |
970-80060-45-00 |
from US $4.56 |
||
|
17
|
17
929-95066-00-00
Washer, Plate
|
929-95066-00-00 |
— | ||
| replacement | |||||
|
17
|
17
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.07 |
||
|
18
|
18
90465-06M67-00 Clamp |
90465-06M67-00 |
from US $5.40 |
||
|
19
|
19
97095-06014-00 Boltボルト; |
97095-06014-00 |
US $1.56 |
||
| replacement | |||||
|
19
|
19
97D95-06014-00 Bolt, Hexagon Deep Rボルト; |
97D95-06014-00 |
from US $1.07 |
||
|
20
|
20
929-95066-00-00
Washer, Plate
|
929-95066-00-00 |
— | ||
| replacement | |||||
|
20
|
20
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.07 |
||
|
21
|
21
676-41662-00-00 Bracket 2ブラケツト; |
676-41662-00-00 |
from US $14.38 |
||
|
22
|
22
97095-06020-00 Boltボルト; |
97095-06020-00 |
US $1.56 |
||
| replacement | |||||
|
22
|
22
970-80060-20-00 Boltボルト; |
970-80060-20-00 |
from US $1.56 |
||
|
23
|
23
929-95066-00-00
Washer, Plate
|
929-95066-00-00 |
— | ||
| replacement | |||||
|
23
|
23
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.07 |
||
|
24
|
24
69J-41213-00-00 Cam, Accel |
69J-41213-00-00 |
US $15.73 |
||
| replacement | |||||
|
24
|
24
69J-41213-02-00 Cam, Accel |
69J-41213-02-00 |
from US $15.73 |
||
|
25
|
25
69J-44135-00-00 Spring |
69J-44135-00-00 |
from US $6.52 |
||
|
26
|
26
90109-06040-00 Bolt |
90109-06040-00 |
from US $11.48 |
||
|
27
|
27
90206-10M04-00 Washer, Waveワツシヤ，ウエイブ; |
90206-10M04-00 |
from US $1.84 |
||
|
28
|
28
90201-10M02-00 Washer, Plateワツシヤ，プレート; |
90201-10M02-00 |
from US $1.98 |
||
|
29
|
29
6E5-42137-10-00 Indicator, Throttleインジケータ，スロツトル; |
6E5-42137-10-00 |
from US $4.14 |
||
