Cylinder & crankcase 2 Diagram Yamaha F225 ETX
- Year
- 2007
- Model
- F225A
- Model code
- 69J
- Year
- 2007
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Power
- 225
- Sales region
- Europe (General) (040)
- Colour
- Dark Bluish Gray 1 (DBN1; 008D)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
69J-W009A-05-1S
Cylinder Head Complete
|
69J-W009A-05-1S |
— | ||
| replacements | |||||
|
01
|
01
69J-W009A-05-9S Cylinder Head Complete |
69J-W009A-05-9S |
US $3,405.60 |
||
|
01
|
01
69J-W009A-06-9S Cylinder Head Complete |
69J-W009A-06-9S |
from US $3,489.90 |
||
|
01
|
01
69J-W009A-06-9S Cylinder Head Complete |
69J-W009A-06-9S |
from US $3,489.90 |
||
|
02
|
02
69J-11110-01-94
Cylinder Head Assy
|
69J-11110-01-94 |
— | ||
| replacement | |||||
|
02
|
02
69J-11110-01-00 Cylinder Head Assy |
69J-11110-01-00 |
from US $2,257.20 |
||
|
03
|
03
69J-11133-10-00 Guide, Valve 1 |
69J-11133-10-00 |
from US $31.88 |
||
|
04
|
04
903-44510-19-00
Plug, Taper Screw
|
903-44510-19-00 |
— | ||
| replacement | |||||
|
04
|
04
903-44510-08-00 Plug, Taper Screw |
903-44510-08-00 |
from US $1.62 |
||
|
05
|
05
91809-08006-00 Pin, Dowel |
91809-08006-00 |
from US $1.84 |
||
|
06
|
06
90119-07235-00 Bolt/washer-Cam Caps |
90119-07235-00 |
from US $1.84 |
||
|
07
|
07
90119-07234-00 Bolt, With Washer |
90119-07234-00 |
from US $1.84 |
||
|
08
|
08
69J-W009C-05-1S
Cylinder Head 2 Complete
|
69J-W009C-05-1S |
— | ||
| replacements | |||||
|
08
|
08
69J-W009C-05-9S Cylinder Head 2 Complete |
69J-W009C-05-9S |
US $3,405.60 |
||
|
08
|
08
69J-W009C-06-9S Cylinder Head 2 Complete |
69J-W009C-06-9S |
from US $3,405.60 |
||
|
09
|
09
69J-11120-01-94
Cylinder Head Assy 2
|
69J-11120-01-94 |
— | ||
| replacement | |||||
|
09
|
09
69J-11120-01-00 Cylinder Head Assy 2 |
69J-11120-01-00 |
from US $2,336.40 |
||
|
10
|
10
69J-11133-10-00 Guide, Valve 1 |
69J-11133-10-00 |
from US $31.88 |
||
|
11
|
11
903-44510-19-00
Plug, Taper Screw
|
903-44510-19-00 |
— | ||
| replacement | |||||
|
11
|
11
903-44510-08-00 Plug, Taper Screw |
903-44510-08-00 |
from US $1.62 |
||
|
12
|
12
91809-08006-00 Pin, Dowel |
91809-08006-00 |
from US $1.84 |
||
|
13
|
13
90119-07235-00 Bolt/washer-Cam Caps |
90119-07235-00 |
from US $1.84 |
||
|
14
|
14
90119-07234-00 Bolt, With Washer |
90119-07234-00 |
from US $1.84 |
||
|
15
|
15
69J-11301-10-00 Anode Cover Assy |
69J-11301-10-00 |
US $17.14 |
||
| replacement | |||||
|
15
|
15
69J-11301-11-00 ANODE COVER ASSY |
69J-11301-11-00 |
from US $17.14 |
||
|
16
|
16
68V-11325-02-00 Anode |
68V-11325-02-00 |
from US $11.05 |
||
|
17
|
17
67F-11328-00-00
Grommet, Anode
|
67F-11328-00-00 |
— | ||
| replacement | |||||
|
17
|
17
67F-11328-01-00 GROMMET ANODE |
67F-11328-01-00 |
from US $2.27 |
||
|
18
|
18
90105-06M07-00 Bolt, Flange |
90105-06M07-00 |
from US $2.16 |
||
|
19
|
19
90430-06M03-00 Gasket |
90430-06M03-00 |
from US $1.34 |
||
|
20
|
20
97575-08540-00 Bolt, With Washer |
97575-08540-00 |
US $5.10 |
||
| replacement | |||||
|
20
|
20
97E75-08540-00 Bolt, Hexagon W/w Deep Recess |
97E75-08540-00 |
from US $2.41 |
||
|
21
|
21
69J-11181-03-00 Gasket, Cylinder Head 1 |
69J-11181-03-00 |
from US $132.58 |
||
|
22
|
22
90387-10M08-00 Collar |
90387-10M08-00 |
from US $1.56 |
||
| replacement | |||||
|
22
|
22
99530-14016-00 Pin, Dowel |
99530-14016-00 |
from US $1.56 |
||
|
23
|
23
90155-10001-00 Screw, Flat Fillister |
90155-10001-00 |
from US $11.48 |
||
|
24
|
24
90119-08M91-00 Bolt, With Washer |
90119-08M91-00 |
from US $4.25 |
||
|
25
|
25
90119-08021-00 Bolt, With Washer |
90119-08021-00 |
from US $6.38 |
||
|
26
|
26
69J-11182-03-00 Gasket, Cylinder Head 2 |
69J-11182-03-00 |
from US $154.40 |
||
|
27
|
27
90387-10M08-00 Collar |
90387-10M08-00 |
from US $1.56 |
||
| replacement | |||||
|
27
|
27
99530-14016-00 Pin, Dowel |
99530-14016-00 |
from US $1.56 |
||
|
28
|
28
90155-10001-00 Screw, Flat Fillister |
90155-10001-00 |
from US $11.48 |
||
|
29
|
29
90119-08M91-00 Bolt, With Washer |
90119-08M91-00 |
from US $4.25 |
||
|
30
|
30
90119-08021-00 Bolt, With Washer |
90119-08021-00 |
from US $6.38 |
||
|
31
|
31
69J-11191-00-1S Cover, Cylinder Head 1 |
69J-11191-00-1S |
US $391.47 |
||
| replacement | |||||
|
31
|
31
69J-11191-00-9S Cover, Cylinder Head 1 |
69J-11191-00-9S |
from US $372.40 |
||
|
32
|
32
69J-11135-00-00 Plate, Breather 3 |
69J-11135-00-00 |
from US $12.04 |
||
|
33
|
33
98507-04008-00 Screw, Pan Head |
98507-04008-00 |
from US $1.07 |
||
|
34
|
34
92907-04600-00 Washer(Jf2) |
92907-04600-00 |
from US $1.07 |
||
|
35
|
35
69J-11193-01-00 Gasket, Head Cover 1 |
69J-11193-01-00 |
from US $41.45 |
||
|
36
|
36
970-95060-30-00
Bolt
|
970-95060-30-00 |
— | ||
| replacement | |||||
|
36
|
36
97080-06030-00 Bolt |
97080-06030-00 |
from US $2.83 |
||
|
37
|
37
929-95066-00-00
Washer, Plate
|
929-95066-00-00 |
— | ||
| replacement | |||||
|
37
|
37
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.07 |
||
|
38
|
38
69J-11192-00-1S Cover, Cylinder Head 2 |
69J-11192-00-1S |
US $307.93 |
||
| replacement | |||||
|
38
|
38
69J-11192-00-9S Cover, Cylinder Head 2 |
69J-11192-00-9S |
US $307.93 |
||
|
39
|
39
69J-11194-00-00 Gasket, Head Cover 2 |
69J-11194-00-00 |
from US $41.86 |
||
|
40
|
40
970-95060-30-00
Bolt
|
970-95060-30-00 |
— | ||
| replacement | |||||
|
40
|
40
97080-06030-00 Bolt |
97080-06030-00 |
from US $2.83 |
||
|
41
|
41
929-95066-00-00
Washer, Plate
|
929-95066-00-00 |
— | ||
| replacement | |||||
|
41
|
41
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.07 |
||
|
42
|
42
94702-00391-00 Plug, Spark (Ngk Lfr5A-11) |
94702-00391-00 |
from US $8.60 |
||
| replacement | |||||
|
42
|
42
LFR-5A110-00-00 Plug, Spark (Ngk Lfr5A-11) |
LFR-5A110-00-00 |
US $61.56 |
||
