Ca175 transmission Diagram Honda CA175 Touring
- Year
- 1968
- Model code
- CA175 A
- Sales region
- USA
- Frame
- CD1751000001 -
- Engine Capacity
- 175
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
13495-200-000
Ring a
|
13495-200-000 |
— | ||
|
2
|
2
23211-216-020
Mainshaft, trans
|
23211-216-020 |
— | ||
|
3
|
3
23221-216-010
Countershaft (26t)
|
23221-216-010 |
— | ||
|
4
|
4
23420-216-000
Gear (36t)
|
23420-216-000 |
— | ||
|
5
|
5
23431-216-000
Gear (18t)
|
23431-216-000 |
— | ||
|
6
|
6
23441-216-010
Gear (32t)
|
23441-216-010 |
— | ||
|
7
|
7
23451-216-010
Gear, third
|
23451-216-010 |
— | ||
|
8
|
8
23460-216-000
Gear (18t)
|
23460-216-000 |
— | ||
|
9
|
9
23471-216-000
Gear (25t)
|
23471-216-000 |
— | ||
|
10
|
10
23801-216-812
Sprocket,drive
|
23801-216-812 |
— | ||
|
11
|
11
9501492100 Plate b, fixing |
9501492100 |
from US $0.81 |
||
|
12
|
12
23931-216-000
Bush, bearing
|
23931-216-000 |
— | ||
|
13
|
13
23932-246-000
Bushb,bearing15mm
|
23932-246-000 |
— | ||
|
14
|
14
24261-283-000 Pin |
24261-283-000 |
from US $4.22 |
||
|
15
|
15
90061-216-000
Bolt, stud (8x152)
|
90061-216-000 |
— | ||
|
16
|
16
90451-230-000
Washer a, thrust
|
90451-230-000 |
— | ||
|
17
|
17
94301-10140 Pin aDOWEL, 10X14 |
94301-10140 |
from US $1.04 |
||
|
18
|
18
91003-235-000 B/brg rad n/com |
91003-235-000 |
US $16.05 |
||
|
19
|
19
91201-216-005
Oil seal, 20x52x9
|
91201-216-005 |
— | ||
|
20
|
20
91204-MB0-013 Oil seal (8x25x8) |
91204-MB0-013 |
from US $2.65 |
||
|
21
|
21
92101-06010-0A Bolt, hex., 6x10 |
92101-06010-0A |
from US $0.44 |
||
|
22
|
22
94510-20000 CirclipEXTERNAL, 20MM |
94510-20000 |
from US $0.55 |
