Left handle switch + cable Diagram Honda CB500 CB500
- Model code
- CB500K2 A
- Sales region
- USA
- Frame
- CB5002100001 -
- Engine Capacity
- 500
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
22870-323-020 Cable,clutch |
22870-323-020 |
US $44.08 |
||
|
2
|
2
35250-300-033 Switch winker |
35250-300-033 |
from US $125.94 |
||
|
3
|
3
35317-001-310 Buttun, horn |
35317-001-310 |
from US $4.88 |
||
|
4
|
4
35317-310-810
Knob,winker swit
|
35317-310-810 |
— | ||
|
5
|
5
35318-259-000 Spring |
35318-259-000 |
from US $3.11 |
||
|
6
|
6
95010-16001 Cap.handle.lever |
95010-16001 |
from US $2.07 |
||
|
7
|
7
53178-369-700 Lever,strg.handle |
53178-369-700 |
from US $20.94 |
||
|
8
|
8
53192-312-000 Bolt |
53192-312-000 |
from US $9.32 |
||
|
9
|
9
88120-323-610
Mirror, l. back
Use up to Frame SN 2107093 |
88120-323-610 |
— | ||
|
10
|
10
88120-333-611 L.back mirrorUse from Frame SN 2107093 |
88120-333-611 |
US $42.42 |
||
|
11
|
11
90114-310-000 Bolt |
90114-310-000 |
from US $5.77 |
||
|
12
|
12
90321-315-670 Nut, fixing |
90321-315-670 |
from US $5.83 |
||
|
13
|
13
90501-310-000 Washer (7x12) |
90501-310-000 |
from US $2.07 |
||
|
14
|
14
93500-050-250-A ScrewPAN, 5X25 |
93500-050-250-A |
from US $0.44 |
||
|
15
|
15
94001-062-000-S NutHEX., 6MM |
94001-062-000-S |
from US $0.44 |
||
|
16
|
16
94111-05000 WasherSPRING, 5MM |
94111-05000 |
from US $0.37 |
||
|
17
|
17
53166-342-670 Rubber,l grip |
53166-342-670 |
from US $16.46 |
