Rear shock absorber m1 Diagram Honda CR250
- Model code
- CR250M1 A
- Sales region
- USA
- Frame
- CR250M2000001 - CR250M2005434
- Engine Capacity
- 250
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
52400-381-003
Coshion assy,rr.
|
52400-381-003 |
— | ||
|
2
|
2
52401-381-003
Spring, rr. shock
|
52401-381-003 |
— | ||
|
3
|
3
52403-360-700
Joint comp.,upper
|
52403-360-700 |
— | ||
|
4
|
4
52405-357-020
Guide, rr.
|
52405-357-020 |
— | ||
|
5
|
5
52410-381-003
Damper, rr.
|
52410-381-003 |
— | ||
|
6
|
6
52411-381-003
Guide, rod
|
52411-381-003 |
— | ||
|
7
|
7
52412-381-003
Seat, damper stopper
|
52412-381-003 |
— | ||
|
8
|
8
52414-381-003
Spring
|
52414-381-003 |
— | ||
|
9
|
9
52415-381-003
Valve (lower)
|
52415-381-003 |
— | ||
|
10
|
10
52420-381-003
Case, shock absorber
|
52420-381-003 |
— | ||
|
11
|
11
52422-357-020
Adjuster, rr.
|
52422-357-020 |
— | ||
|
12
|
12
52430-381-003
Cylinder
|
52430-381-003 |
— | ||
|
13
|
13
52440-381-003
Rod, shock absorber
|
52440-381-003 |
— | ||
|
14
|
14
52459-360-700
Seat, spring (upper)
|
52459-360-700 |
— | ||
|
15
|
15
52517-360-700 Rubber, stopper |
52517-360-700 |
US $11.69 |
||
|
16
|
16
91256-381-000
Oil seal
|
91256-381-000 |
— | ||
|
17
|
17
91317-381-000
O-ring (30.8x1.9)
|
91317-381-000 |
— | ||
|
18
|
18
92101-10032-0A Bolt, hex., 10x32 |
92101-10032-0A |
US $0.74 |
||
|
19
|
19
94002-120-000-S NutHEX., 12MM |
94002-120-000-S |
from US $0.59 |
||
|
20
|
20
9410110000 Washer, plain, 10mm |
9410110000 |
from US $0.44 |
