Exhaust manifold 84 Diagram Honda CR250
- Year
- 1984
- Model code
- CR250R A
- Sales region
- USA
- Frame
- JH2ME030*EC600001 - JH2ME030*EC607757
- Engine Capacity
- 250
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
12303-KA4-740
Cover, atac
|
12303-KA4-740 |
— | ||
|
2
|
2
12304-KA4-405
Separator
|
12304-KA4-405 |
— | ||
|
3
|
3
12305-KA4-405
Gasket, atac cover
|
12305-KA4-405 |
— | ||
|
4
|
4
18291-KA4-306
Gasket, ex. manifold
|
18291-KA4-306 |
— | ||
|
5
|
5
18345-KA4-740
Cover,manifold
|
18345-KA4-740 |
— | ||
|
6
|
6
18349-KA4-405
Gsk.mnfld cover
|
18349-KA4-405 |
— | ||
|
7
|
7
18350-KA4-740
Lever butterfly
|
18350-KA4-740 |
— | ||
|
8
|
8
18353-KA4-740
Valve,butterfly
|
18353-KA4-740 |
— | ||
|
9
|
9
18354-KA3-740
Cotter butt shaft
|
18354-KA3-740 |
— | ||
|
10
|
10
18355-KA4-740
Shaft,butterfly
|
18355-KA4-740 |
— | ||
|
11
|
11
18359-KA4-740
Seal,exh mnfld
|
18359-KA4-740 |
— | ||
|
12
|
12
18360-KA4-740
Manifold ex
|
18360-KA4-740 |
— | ||
|
13
|
13
18370-KA4-740
Shaft set,rr butt
|
18370-KA4-740 |
— | ||
|
14
|
14
19243-KA4-740
Roller,atac
|
19243-KA4-740 |
— | ||
|
15
|
15
19244-KA4-740
Shaft,atac
|
19244-KA4-740 |
— | ||
|
16
|
16
19245-KA4-740
Holder,atac shaft
|
19245-KA4-740 |
— | ||
|
17
|
17
19246-KA4-740
Pin,atac holder
|
19246-KA4-740 |
— | ||
|
18
|
18
19310-KA4-740
Lever comp.,atac
|
19310-KA4-740 |
— | ||
|
19
|
19
19320-KA4-740
Link comp.,rh.
|
19320-KA4-740 |
— | ||
|
20
|
20
19323-KA4-740
Pivot,rh.link
|
19323-KA4-740 |
— | ||
|
21
|
21
19325-KA4-740
Rod,horiz
|
19325-KA4-740 |
— | ||
|
22
|
22
19330-KA4-740
Link comp.,lh.
|
19330-KA4-740 |
— | ||
|
23
|
23
19333-KA4-740
Pivot,upper link
|
19333-KA4-740 |
— | ||
|
24
|
24
19334-KA4-740
Pivot,lh.link
|
19334-KA4-740 |
— | ||
|
25
|
25
19335-KA4-740
Rod,vert
|
19335-KA4-740 |
— | ||
|
26
|
26
19336-KA4-740
Spg,adjr
|
19336-KA4-740 |
— | ||
|
27
|
27
19339-KA4-740
Rod,upper
|
19339-KA4-740 |
— | ||
|
28
|
28
19350-KA4-740
Link fr.upper
|
19350-KA4-740 |
— | ||
|
29
|
29
19355-KA4-740
Spg,over stroke
|
19355-KA4-740 |
— | ||
|
30
|
30
19360-KA4-740
Link upper,rr.
|
19360-KA4-740 |
— | ||
|
31
|
31
90021-KS6-000
Bolt, sealing (8mm)
|
90021-KS6-000 |
— | ||
|
32
|
32
90442-KA3-740
Plate spg hanger
|
90442-KA3-740 |
— | ||
|
33
|
33
90459-KA4-740
Washer,lock
|
90459-KA4-740 |
— | ||
|
34
|
34
90541-KA3-740
Washer (8x13x0.5)
|
90541-KA3-740 |
— | ||
|
35
|
35
90556-KA4-740
Collar,13mm
|
90556-KA4-740 |
— | ||
|
36
|
36
90601-816-000
Clip,5mm
|
90601-816-000 |
— | ||
|
37
|
37
90602-KA4-741 Cir clip ex6 |
90602-KA4-741 |
US $4.81 |
||
|
38
|
38
90603-KA4-741
E ring 3.7
|
90603-KA4-741 |
— | ||
|
39
|
39
90607-081-000 Circlip7MM |
90607-081-000 |
from US $2.37 |
||
|
40
|
40
91202-KA4-741
Oil seal 10x18x4
|
91202-KA4-741 |
— | ||
|
41
|
41
92301-04008-0A Bolt,slotted 4x8 |
92301-04008-0A |
from US $0.44 |
||
|
42
|
42
90014-KA4-740
Screw-washer (4x8)
Use from Engine SN 2602257 |
90014-KA4-740 |
— | ||
|
42
|
42
93892-0400800 Screw-washer, 4x8Use up to Engine SN 2602256 |
93892-0400800 |
from US $0.47 |
||
|
43
|
43
94001-040-000-S NutHEX., 4MM |
94001-040-000-S |
from US $0.37 |
||
|
44
|
44
94101-05000 WasherPLAIN, 5MM |
94101-05000 |
from US $0.37 |
||
|
45
|
45
94303-03050 Dowel pin3X5 |
94303-03050 |
from US $0.81 |
||
|
46
|
46
96001-060-200-0 BoltFLANGE, 6X20 |
96001-060-200-0 |
from US $0.59 |
||
|
47
|
47
96001-0602200 Bolt, flange, 6x22 |
96001-0602200 |
from US $0.74 |
||
|
48
|
48
96000-0602500 Bolt, flange, 6x25 |
96000-0602500 |
US $24.50 |
||
| replacement | |||||
|
48
|
48
96001-060-250-0 BoltFLANGE, 6X25 |
96001-060-250-0 |
from US $0.74 |
||
|
48
|
48
96001-060-250-0 BoltFLANGE, 6X25 |
96001-060-250-0 |
from US $0.74 |
||
|
49
|
49
96001-060-280-0 BoltFLANGE, 6X28 |
96001-060-280-0 |
from US $0.74 |
||
