Exhaust valve (1) Diagram Honda CR250
- Year
- 1986
- Model code
- CR250RG
- Sales region
- Europe
- Frame
- JH2ME030*GC800331 - JH2ME030*GC808877
- Engine Capacity
- 250
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
12106-KS7-000
Cover, r
|
12106-KS7-000 |
— | ||
|
2
|
2
12107-KS7-000 Cover, l |
12107-KS7-000 |
US $30.57 |
||
|
3
|
3
12108-KS7-000
Superceded
|
12108-KS7-000 |
— | ||
| replacement | |||||
|
3
|
3
12108-KS7-880
Gasket
|
12108-KS7-880 |
— | ||
|
4
|
4
12111-KS7-000
Cover, r. cylinder
|
12111-KS7-000 |
— | ||
|
5
|
5
12112-KS7-000
Cover, l. cylinder
|
12112-KS7-000 |
— | ||
|
6
|
6
12113-KS7-000
Superceded
|
12113-KS7-000 |
— | ||
| replacement | |||||
|
6
|
6
12113-KS7-P00
Gasket, l
|
12113-KS7-P00 |
— | ||
|
7
|
7
12114-KS7-000
Superceded
|
12114-KS7-000 |
— | ||
| replacement | |||||
|
7
|
7
12114-KS7-P00
Gasket, r. (upper)
|
12114-KS7-P00 |
— | ||
|
8
|
8
14430-KS7-000
Lever comp.,r.ex.
|
14430-KS7-000 |
— | ||
|
10
|
10
14440-KS7-000
Lever comp.,l.ex.
|
14440-KS7-000 |
— | ||
|
12
|
12
14451-KS7-000
Lever,adjuster
|
14451-KS7-000 |
— | ||
|
13
|
13
14461-KS7-000
Collar
|
14461-KS7-000 |
— | ||
|
14
|
14
14600-KS7-000
Valve assy.,r.ex.
|
14600-KS7-000 |
— | ||
|
16
|
16
14700-KS7-000
Valve assy.,l.ex.
|
14700-KS7-000 |
— | ||
|
18
|
18
14751-KS7-000
Spring,r.ex.valve
|
14751-KS7-000 |
— | ||
| replacement | |||||
|
18
|
18
14751-KS7-010
Spg,r exh valve
|
14751-KS7-010 |
— | ||
|
19
|
19
14752-KS7-000
Spring,l.ex.valve
|
14752-KS7-000 |
— | ||
| replacement | |||||
|
19
|
19
14752-KS7-010
Spg.,l exh valve
|
14752-KS7-010 |
— | ||
|
20
|
20
14761-KS7-000
Spring,r.valve pr
|
14761-KS7-000 |
— | ||
|
21
|
21
14762-KS7-000
Spring,l.valve pr
|
14762-KS7-000 |
— | ||
|
22
|
22
14771-KS7-000
Collar,valve spri
|
14771-KS7-000 |
— | ||
| replacement | |||||
|
22
|
22
14771-KS7-020
Collar,valve spg.
|
14771-KS7-020 |
— | ||
|
23
|
23
19310-KA4-770
Arm comp.,rocker
|
19310-KA4-770 |
— | ||
|
24
|
24
19321-KA3-740
Holder, rocker arm
|
19321-KA3-740 |
— | ||
|
25
|
25
19322-KA3-740
Pin, rocker arm
|
19322-KA3-740 |
— | ||
|
26
|
26
19331-KS7-000
Spring a,valve
|
19331-KS7-000 |
— | ||
|
27
|
27
19343-KA3-740
Retainer spg a
|
19343-KA3-740 |
— | ||
|
28
|
28
19345-KA3-760
Guide,spg outer
|
19345-KA3-760 |
— | ||
|
29
|
29
19351-KS7-000
Spindle,cam
|
19351-KS7-000 |
— | ||
|
30
|
30
19352-KA3-741
Cam,follow
|
19352-KA3-741 |
— | ||
|
31
|
31
19355-KA4-770
Bush,cam spindle
|
19355-KA4-770 |
— | ||
|
32
|
32
19360-KS7-000
Shaft comp.,pinio
|
19360-KS7-000 |
— | ||
|
33
|
33
19361-KS7-000
Rack,exh.valve
|
19361-KS7-000 |
— | ||
|
34
|
34
90011-KS6-000
Screw,butterfly s
|
90011-KS6-000 |
— | ||
|
35
|
35
90012-KA3-740
Bolt spcl 6x23
|
90012-KA3-740 |
— | ||
|
36
|
36
90021-KS7-000
Bolt,sealing 8mm
|
90021-KS7-000 |
— | ||
|
37
|
37
90022-KS6-000
Bolt,spl,8x6.5
|
90022-KS6-000 |
— | ||
| replacement | |||||
|
37
|
37
90022-GC4-730
Bolt,specal8x6.5
|
90022-GC4-730 |
— | ||
|
38
|
38
90201-KA3-740
Nut lock 5mm
|
90201-KA3-740 |
— | ||
|
39
|
39
90408-KS7-000
Washer,6.5x16
|
90408-KS7-000 |
— | ||
|
40
|
40
90417-360-000 Washer, drum stopper |
90417-360-000 |
from US $2.07 |
||
|
42
|
42
90503-KS7-000
Washer (7.6x16)
|
90503-KS7-000 |
— | ||
|
43
|
43
90541-KA3-740
Washer (8x13x0.5)
|
90541-KA3-740 |
— | ||
|
44
|
44
90543-273-000 Gasket, fr. |
90543-273-000 |
from US $2.03 |
||
|
45
|
45
90601-KS7-003 Circlip (10mm) |
90601-KS7-003 |
from US $2.28 |
||
|
46
|
46
93500-050-120-A ScrewPAN, 5X12 |
93500-050-120-A |
from US $0.37 |
||
|
47
|
47
94050-06080 NutFLANGE, 6MM |
94050-06080 |
from US $0.50 |
||
|
48
|
48
9425105000 Pin, lock, 5mm |
9425105000 |
from US $0.47 |
||
|
49
|
49
94540-06018 E-ring6MM |
94540-06018 |
from US $1.41 |
||
|
50
|
50
96000-0601400 Bolt, flange (6x14) |
96000-0601400 |
from US $0.59 |
||
| replacement | |||||
|
50
|
50
96001-060-140-0 BoltFLANGE, 6X14 |
96001-060-140-0 |
from US $0.59 |
||
|
51
|
51
96000-0602007 Bolt, flange (6x20) |
96000-0602007 |
from US $0.59 |
||
| replacement | |||||
|
51
|
51
96001-0602007 Bolt, flange (6x20) |
96001-0602007 |
from US $0.65 |
||
