Air cleaner Diagram Honda CX650
- Year
- 1983
- Model code
- CX650T A
- Sales region
- USA
- Frame
- JH2RC160*DM000023 - JH2RC160*DM001139
- Engine Capacity
- 650
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
14200-ME7-013
Valve assy., reed
Use up to Frame SN DM000649 |
14200-ME7-013 |
— | ||
|
2
|
2
14203-ME7-000
Gasket, reed valve
|
14203-ME7-000 |
— | ||
|
3
|
3
17202-MC7-000
Ring, reed valve
|
17202-MC7-000 |
— | ||
|
4
|
4
17203-ME7-000
Chamber, reed valve
|
17203-ME7-000 |
— | ||
|
5
|
5
17204-MC7-000
Net,air cleaner
|
17204-MC7-000 |
— | ||
|
6
|
6
17205-ME7-000
Patch, reed valve
|
17205-ME7-000 |
— | ||
|
7
|
7
17207-MC7-000
Collar
|
17207-MC7-000 |
— | ||
|
8
|
8
17208-ME7-000
Collar b
|
17208-ME7-000 |
— | ||
|
9
|
9
17210-ME7-000
Case,air cleaner
|
17210-ME7-000 |
— | ||
|
10
|
10
17211-MC7-000
Packing,silenser
|
17211-MC7-000 |
— | ||
|
11
|
11
17212-MC7-000
Pkg,air/c element
|
17212-MC7-000 |
— | ||
|
12
|
12
17213-ME7-000
Holder, reed valve
|
17213-ME7-000 |
— | ||
|
13
|
13
17216-MC7-000
Trap comp.,frame
|
17216-MC7-000 |
— | ||
|
14
|
14
17217-MC7-000
Element,air clean
|
17217-MC7-000 |
— | ||
|
15
|
15
17218-MC7-000
Chamber,silencer
|
17218-MC7-000 |
— | ||
|
16
|
16
17219-MC7-000
Cap,silencer
|
17219-MC7-000 |
— | ||
|
17
|
17
17220-ME7-000
Cover,air cleaner
|
17220-ME7-000 |
— | ||
|
18
|
18
17222-ME7-000
Joint, a/clnr hsg
|
17222-ME7-000 |
— | ||
|
19
|
19
17223-ME7-000
Tube,air/c conn
|
17223-ME7-000 |
— | ||
|
20
|
20
17224-ME7-000
Joint a,conn.tube
|
17224-ME7-000 |
— | ||
|
21
|
21
17225-ME7-000
Joint b,conn.tube
|
17225-ME7-000 |
— | ||
|
22
|
22
17226-MC7-000
Pkg,air/c case
|
17226-MC7-000 |
— | ||
|
23
|
23
17227-ME7-000
Ring,conn.tube
|
17227-ME7-000 |
— | ||
|
24
|
24
17228-MC7-000
Bolt,air/c elemen
|
17228-MC7-000 |
— | ||
|
25
|
25
17256-MC7-000
Band,air/c.tube
|
17256-MC7-000 |
— | ||
|
26
|
26
36152-MC7-003
Sensor, air temp
|
36152-MC7-003 |
— | ||
|
27
|
27
93500-040-080-A ScrewPAN, 4X8 |
93500-040-080-A |
from US $0.38 |
||
|
28
|
28
93892-040-200-8 Screw-washer4X20 |
93892-040-200-8 |
US $0.44 |
||
|
29
|
29
95701-060-100-0 BoltFLANGE, 6X10 |
95701-060-100-0 |
from US $0.52 |
