Balancer Diagram Honda XR250
- Year
- 1980
- Model code
- XR250 A
- Sales region
- USA
- Frame
- ME015100001 -
- Engine Capacity
- 250
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
13411-471-000
Shaft,balancer
|
13411-471-000 |
— | ||
|
2
|
2
13412-428-020
Hldr, balancer shaft
|
13412-428-020 |
— | ||
|
3
|
3
13413-428-020
Flange,bal.holder
|
13413-428-020 |
— | ||
|
4
|
4
13414-428-000
Spg,chain adjust
|
13414-428-000 |
— | ||
|
5
|
5
13421-428-000 Wt,fr balancer |
13421-428-000 |
US $48.89 |
||
|
6
|
6
13430-428-000
Slipper,chain
|
13430-428-000 |
— | ||
|
7
|
7
13440-428-003
Chain,balancer
|
13440-428-003 |
— | ||
|
9
|
9
13610-471-000
Sprkt,fr balancer
|
13610-471-000 |
— | ||
|
14
|
14
96001-060-140-0 BoltFLANGE, 6X14 |
96001-060-140-0 |
from US $0.59 |
||
|
15
|
15
90436-611-000
Washer
|
90436-611-000 |
— | ||
|
16
|
16
90456-428-000
Wash special,20mm
|
90456-428-000 |
— | ||
|
17
|
17
90458-292-000 Washer, thrust, 20mm |
90458-292-000 |
from US $3.55 |
||
|
18
|
18
90605-200-000 Set-ring (20mm) |
90605-200-000 |
from US $3.11 |
||
|
19
|
19
91011-P48-008 BearingNEEDLE, 20X26X20 |
91011-P48-008 |
US $31.69 |
||
|
19
|
19
91011-428-008 BearingNEEDLE, 20X26X20 |
91011-428-008 |
US $31.69 |
||
| replacement | |||||
|
19
|
19
91011-P48-008 BearingNEEDLE, 20X26X20 |
91011-P48-008 |
US $31.69 |
||
|
20
|
20
91012-471-008
Needle brg
|
91012-471-008 |
— | ||
|
23
|
23
94510-20000 CirclipEXTERNAL, 20MM |
94510-20000 |
from US $0.55 |
||
|
25
|
25
94510-38000 CirclipEXTERNAL, 38MM |
94510-38000 |
from US $1.04 |
||
|
26
|
26
95701-080-200-0 Bolt, flange, 8x20 |
95701-080-200-0 |
from US $0.59 |
||
