Front fork (Kz1100-a1/a2) Diagram Kawasaki KZ1000 Shaft
- Year
- 1980
- Model code
- KZ1000-E2
- Sales region
- USA
- Engine Capacity
- 1000
- Model
- KZ1000 Shaft
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
114
|
114
114G0855 BOLT-SMALL-UPSET,8X55Bolt,hex head,8x55; |
114G0855 |
US $45.40 |
||
| replacements | |||||
|
114
|
114
115BA0855 BOLT-SMALL-UPSETBolt,hex head,8x55; |
115BA0855 |
US $1.24 |
||
|
114
|
114
115G0855
BOLT-SMALL-UPSET,8X55
Bolt,hex head,8x55; |
115G0855 |
— | ||
|
220
|
220
220B0408
SCREW-PAN-CROS
Screw pan head 4x8; |
220B0408 |
— | ||
| replacement | |||||
|
220
|
220
220AA0408 SCREW-PAN-CROSScrew pan head 4x8; |
220AA0408 |
from US $0.79 |
||
|
220A
|
220A
220B0414
SCREW-PAN-CROS
|
220B0414 |
— | ||
| replacement | |||||
|
220A
|
220A
220AA0414 SCREW-PAN-CROS |
220AA0414 |
from US $1.07 |
||
|
410
|
410
410B0800
WASHER-PLAIN-SMALL,8M
Washer plain 8mm; |
410B0800 |
— | ||
| replacement | |||||
|
410
|
410
410AA0800 WASHER-PLAIN-SMALL,8MWasher plain 8mm; |
410AA0800 |
from US $0.63 |
||
|
11009
|
11009
44045002 GASKET FORK DRAIN PLGGasket fork drain plg; |
44045002 |
from US $3.96 |
||
|
11009A
|
11009A
44045057 GASKET,FORK CYLINDERGasket,fork cylinder; |
44045057 |
from US $3.33 |
||
|
11012
|
11012
11012-1241
CAP,AIR VALVE
Cap,air valve; |
11012-1241 |
— | ||
|
11034
|
11034
11034-1842 BRACKET,FORK COVERBracket,fork cover; |
11034-1842 |
US $20.77 |
||
|
16126
|
16126
16126-1052 VALVE AIRValve air; |
16126-1052 |
from US $23.34 |
||
|
44001A
|
44001A
44001-1302 FORK-FRONT(jkakzba1 ba003574-) |
44001-1302 |
US $1,716.03 |
||
|
44005
|
44005
44005-1067 TUBE,LH,FORK OUTERTube,lh,fork outer; |
44005-1067 |
US $313.87 |
||
|
44006
|
44006
44006-1067 TUBE,RH,FORK OUTERTube,rh,fork outer; |
44006-1067 |
US $313.58 |
||
|
44013
|
44013
44013-1064 PIPE-FORK INNER |
44013-1064 |
US $390.10 |
||
|
44022
|
44022
44022-1045
CYLINDER-FORK
|
44022-1045 |
— | ||
|
44028
|
44028
44028-029 GUIDE-FORK SPRING |
44028-029 |
US $5.26 |
||
|
44028A
|
44028A
44028-1004 GUIDE,FORK SPRINGGuide,fork spring; |
44028-1004 |
from US $8.93 |
||
|
44029
|
44029
44029-1015
CAP,FORK TOP
Cap,fork top; |
44029-1015 |
— | ||
|
44029A
|
44029A
44029-1026
SEAT-FORK SPRING
|
44029-1026 |
— | ||
|
44033
|
44033
44033-1054 COVER,FORKCover,fork; |
44033-1054 |
from US $54.98 |
||
|
44037
|
44037
44037-1074 Holder-fork under |
44037-1074 |
US $421.81 |
||
|
44039
|
44039
44039-1046 HOLDER-FORK UPPER |
44039-1046 |
US $275.11 |
||
|
44065
|
44065
44065-1091 BUSHING-FRONT FORK,OUBushing-front fork,ou; |
44065-1091 |
from US $17.74 |
||
|
51044
|
51044
51044-1008 TUBE ASSY,AIR FORKTube assy,air fork; |
51044-1008 |
US $251.71 |
||
|
92001
|
92001
44041040 BOLT-FORK CYLINDERBolt-fork cylinder; |
44041040 |
from US $4.44 |
||
|
92001A
|
92001A
222C0518 SCREW-CSK-RD-CROS |
222C0518 |
US $2.88 |
||
| replacement | |||||
|
92001A
|
92001A
222AB0518 SCREW-CSK-RD-CROS |
222AB0518 |
from US $0.94 |
||
|
92001B
|
92001B
92001-1358 BOLT,FLANGED,8X57Bolt,flanged,8x57; |
92001-1358 |
US $6.55 |
||
|
92015
|
92015
92015-1022 NUT-8MMNut-8mm; |
92015-1022 |
from US $0.82 |
||
|
92015A
|
92015A
92015-1124 NUT,LOCK,8MMNut,lock,8mm; |
92015-1124 |
from US $3.17 |
||
|
92022
|
92022
92022-1262 WASHER,FORK OUT PIPEWasher,fork out pipe; |
92022-1262 |
from US $5.07 |
||
|
92033
|
92033
92033-1047 SNAP RING,FORK OUTERSnap ring,fork outer; |
92033-1047 |
from US $3.80 |
||
|
92037
|
92037
92037-1277 CLAMP,FRONT FORKClamp,front fork; |
92037-1277 |
US $7.65 |
||
|
92049
|
92049
92049-1295 SEAL-OIL,FORK OUTER TSeal-oil,fork outer t; |
92049-1295 |
from US $15.05 |
||
|
92055
|
92055
92055-1051 0 RING,FORK TOP"0" ring,fork top; |
92055-1051 |
from US $3.17 |
||
|
92055A
|
92055A
92055-1094 O RING,6M/M"0" ring,air valve; |
92055-1094 |
US $0.85 |
||
| replacement | |||||
|
92055A
|
92055A
670B1506 O RING,6M/M"0" ring,air valve; |
670B1506 |
from US $1.62 |
||
|
92055B
|
92055B
92055-1369 RING-O,RODRing-o,rod; |
92055-1369 |
from US $8.15 |
||
|
92093
|
92093
92093-1051 SEAL |
92093-1051 |
from US $16.65 |
||
