Headlight Support Diagram KTM 400 400 Duke
- Year
- 1994
- Sales region
- US/EU
- Engine Capacity
- 400
- Model
- 400 Duke
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
|
58311147001
Headlight support r/s bottom
DUKE'94 |
58311147001 |
— | ||
|
1
|
1
58301098100
Plastic cap 3/8" 2617
2617 |
58301098100 |
— | ||
|
2
|
2
0912040163 Ah screw din0912-m 4x162617 |
0912040163 |
US $1 |
||
|
3
|
3
58311049003 Adjusting button duke'94DUKE'94 |
58311049003 |
US $1.94 |
||
|
5
|
5
58311049002 Adjusting screw m8DUKE'94 |
58311049002 |
US $21.73 |
||
|
6
|
6
0125080003 Washer din0125-a 8,4DUKE'94 |
0125080003 |
US $2.02 |
||
|
7
|
7
31008060000 Rubber Sleeve D=8Mm OpenDUKE'94 |
31008060000 |
US $1.09 |
||
|
9
|
9
546370Z2200
Spring
DUKE'94 |
546370Z2200 |
— | ||
|
10
|
10
58311049000
Adjusting screw bracket duke94
DUKE'94 |
58311049000 |
— | ||
|
11
|
11
0936080003 Hexagon nut din0936-m 8SW=13 |
0936080003 |
US $0.39 |
||
|
13
|
13
54635036000
Bushing
SW=13 |
54635036000 |
— | ||
|
14
|
14
56401040000 Rubber bushingSW=13 |
56401040000 |
US $6.73 |
||
|
15
|
15
0125060003 Washer Din0125-A 6,4SW=13 |
0125060003 |
US $0.37 |
||
|
16
|
16
0912060353 Ah Screw Din0912-M 6X35SW=13 |
0912060353 |
US $2.09 |
||
|
20
|
20
58311009000 Headlight cover duke'94DUKE'94 |
58311009000 |
US $15.11 |
||
|
21
|
21
58311045000
Headlight carrier duke'94
DUKE'94 |
58311045000 |
— | ||
|
22
|
22
58311047000
Headlight support top
DUKE'94 |
58311047000 |
— | ||
|
24
|
24
54335031000 Rubber grommet 20x15-m6x10 (2)DUKE'94 |
54335031000 |
US $10 |
||
|
25
|
25
0912060503 Ah Screw Din0912-M 6X50DUKE'94 |
0912060503 |
US $1.46 |
||
|
26
|
26
58311147000
Headlight support l/s bottom
DUKE'94 |
58311147000 |
— | ||
|
27
|
27
56509064000 Self Locking Nut M6 10.9DUKE'94 |
56509064000 |
US $1.14 |
||
| replacement | |||||
|
27
|
27
56509064100 Self Locking Nut M6 10.9DUKE'94 |
56509064100 |
US $1.04 |
||
|
28
|
28
0934060003 Hexagon Nut Din0934-M 6DUKE'94 |
0934060003 |
US $0.43 |
||
|
29
|
29
0797060003 Tooth Lock Wash. Din6797-A 6,4DUKE'94 |
0797060003 |
US $0.29 |
||
