Parts list

Difficulties in parts search?

	Description	OEM Part #	Price
1	1 59436013000 Timing chain 92 rolls 03 2001	59436013000	US $96.02
1	1 59036013000 Timing chain 96 rolls 2001	59036013000	US $93.72
3	3 59036001000 Timing Chain Guide Racing 2001	59036001000	US $14.55
4	4 59036018000 Securing guide racing 2001	59036018000	US $3.88
5	5 59036014000 Timing gear 18-t 2001	59036014000	US $66.66
6	6 59036002000 Timing chain tensioner 2001	59036002000	US $14.99
7	7 59036003050 Gasket timing chain tensioner 2001	59036003050	US $5.85
8	8 59036003000 Timingchain Tensioner Cpl.rac 2001	59036003000	US $63.33
9	9 59036001050 Spacer bushing 6,1x8,2x13,1 2001	59036001050	US $2.41
10	10 0015060203 Hh Collar Screw M 6X20 Ws=8 2001	0015060203	—
	replacement
10	10 0025060206 Hh collar screw m6x20 tx30 2001	0025060206	US $1.97
11	11 0015050163 Hh Collar Screw M 5X16 Ws=8 2001	0015050163	US $1.31
12	12 59036018050 Supporting sleeve 5,2x7x10x7,7 2001	59036018050	US $2.57
15	15 0603061001 Cu-Seal Ring Din7603-6X10X1 2001	0603061001	US $2.64
16	16 0015060253 Hh Collar Screw M6X25 Tx30 2001	0015060253	—
	replacement
16	16 0025060256 Hh collar screw m6x25 tx30 2001	0025060256	US $2.45
17	17 0015060303 Hh Collar Screw M6X30 Tx30 2001	0015060303	—
	replacement
17	17 0025060306 Hh collar screw m6x30 tx30 2001	0025060306	US $3.96
18	18 59436001050 Spacer bushing 2001	59436001050	US $2.65
19	19 0125060003 Washer Din0125-A 6,4 2001	0125060003	US $0.37
24	24 59036010000 Camshaft 590/5521 2000 2001	59036010000	US $234.26
26	26 59036011100 Camshaft gear 2003 2001	59036011100	US $58.31
27	27 59036016000 Auto decompression shaft 2001	59036016000	—
29	29 0984080103 Ah screw din7984-m 8x10 2001	0984080103	US $1.09
32	32 59036082000 Washer 26,7x34x1,3 2001	59036082000	US $4.64
33	33 59036081100 Gasket support 2001	59036081100	US $17.77
34	34 0625062014 Ball Bearing 6201 2001	0625062014	US $16.47
35	35 59036017000 Spring for autodecompression 2001	59036017000	US $2.72
37	37 0770291016 O-Ring 29,10X1,60 Nbr 70 2001	0770291016	US $1.16
38	38 0770020220 O-ring 25,12x1,78 nbr70 2001	0770020220	US $3.89
40	40 0760101843 Shaft Seal Ring 10X18X4 Bsl V 2001	0760101843	—
	replacement
40	40 0760101844 Shaft Seal Ring 10X18X4 Bsl V 2001	0760101844	US $9.96
41	41 59036013050 Rivet link for timing chain 2001	59036013050	US $10.17
43	43 0402031780 Needle rol.din5402 nrb 3x17,8 2001	0402031780	US $1.29
44	44 59035055144 Water pump wheel cpl. rac.2001 2001	59035055144	US $6.15
45	45 0471100010 Circlip 2001	0471100010	US $1.16

Timing Valve Diagram KTM 525 525 SMR US/EU 18099560-940376

Timing Valve Diagram KTM 525 525 SMR US/EU 18099560-940376
