Suspension, strut and hanger mounting (V05TB16/ALL OPTIONS) Diagram Polaris CA TOURING CRUISER ALL OPTIONS
- Year
- 2005
- Sales region
- General
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5811941 Pad,rubber,tandem seat |
5811941 |
US $8.17 |
||
|
2
|
2
1013951-067
Weld-strut,lh,blk
|
1013951-067 |
— | ||
|
2
|
2
1013952-067 Strut,rh,blk |
1013952-067 |
US $160.55 |
||
|
3
|
3
5133702 Bushing-fender,rear,sil |
5133702 |
US $7.18 |
||
|
4
|
4
7518155 Scr-schflthd,m8x20,0600085 |
7518155 |
US $34.65 |
||
|
5
|
5
7517838 Scr-hexflghd,m8 x 20,0600086 |
7517838 |
US $5.95 |
||
|
6
|
6
1013641
Asm., cover strut, lh
Incl. Clips; |
1013641 |
— | ||
|
6
|
6
1013642
Asm., cover strut, rh
Incl. Clips; |
1013642 |
— | ||
|
6
|
6
7670139 Clip-strut (10) |
7670139 |
US $6.69 |
||
|
7
|
7
7517887 Scr-hexhd,m8x12,0600088(10) |
7517887 |
US $2.98 |
||
|
8
|
8
7556164 Wshr-fl,8,4x1,6x16,0600090(10) |
7556164 |
US $0.84 |
||
|
9
|
9
5246681 Brkt-luggage rack,tc |
5246681 |
US $41.76 |
||
|
10
|
10
7517888 Scr-hexhd,m8x16,0600088 |
7517888 |
US $14.40 |
||
|
11
|
11
7517951 Scr-hexflghd,m10x16,0600086 |
7517951 |
US $3.94 |
||
|
12
|
12
1012963-067 Weld-hanger,rear,blk |
1012963-067 |
US $96.51 |
||
|
13
|
13
1013164-342
Fender,rear,p342 red **
|
1013164-342 |
— | ||
|
13
|
13
1013164-352
Fender,rear,tc,pwh
|
1013164-352 |
— | ||
|
13
|
13
1013164-469
Fender,rear,tc,mbm
|
1013164-469 |
— | ||
|
13
|
13
1013164-266 Weld-fender,rear,p266/blk |
1013164-266 |
US $1,151.19 |
||
|
13
|
13
1013164-341
Weld-fender,rear,p341/blue
|
1013164-341 |
— | ||
|
14
|
14
7547076
Nut,hexhd,m8
|
7547076 |
— | ||
|
15
|
15
2874780
Luggage rack, tc
|
2874780 |
— |
