Right handle switch Diagram Suzuki DR125
- Year
- 1984
- Model code
- DR125SE E
- Engine Capacity
- 125
- Model
- DR125S
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
57110-37200-000
GRIP,THROTTLE
|
57110-37200-000 |
— | ||
| replacement | |||||
|
1
|
1
57110-37201-000 Grip,throttle |
57110-37201-000 |
from US $18.20 |
||
|
2
|
2
57100-37400-000 CASE ASSY,THROTTLECase assy, throttle |
57100-37400-000 |
from US $49.68 |
||
|
3
|
3
02112-05208-000
Screw
|
02112-05208-000 |
— | ||
| replacement | |||||
|
3
|
3
02112-05207-000 SCREW |
02112-05207-000 |
from US $3.11 |
||
|
4
|
4
57300-05200-000
Lever assy, brake
|
57300-05200-000 |
— | ||
| replacement | |||||
|
4
|
4
57300-05210-000
Lever/switch assy,brake
|
57300-05210-000 |
— | ||
|
5
|
5
57420-26400-000 LEVER,BRAKE |
57420-26400-000 |
from US $31.64 |
||
|
6
|
6
57431-11011-000 Bolt |
57431-11011-000 |
US $6.32 |
||
| replacement | |||||
|
6
|
6
57431-11013-000 BOLT,LEVER PIVOT |
57431-11013-000 |
from US $2.72 |
||
|
7
|
7
08319-21068-000
U nut
Nut; |
08319-21068-000 |
— | ||
| replacement | |||||
|
7
|
7
08319-2106A-000 NUTNut; |
08319-2106A-000 |
from US $1.28 |
||
|
8
|
8
02112-06208-000
Screw
|
02112-06208-000 |
— | ||
| replacement | |||||
|
8
|
8
02112-06207-000 SCREW |
02112-06207-000 |
from US $0.80 |
||
|
9
|
9
57441-26010-000 ADJUSTER,CABLEAdjuster, cable Adjuster, cable; |
57441-26010-000 |
from US $2.46 |
||
|
10
|
10
57442-11010-000 NUT,CABLE ADJUSTERNut Nut; |
57442-11010-000 |
from US $1.67 |
||
|
11
|
11
57341-40001-000
Lever dust cove
|
57341-40001-000 |
— | ||
| replacements | |||||
|
11
|
11
57341-40002-000
COVER,CLUTCH LEVER
|
57341-40002-000 |
— | ||
|
11
|
11
57341-40003-000 Cover,clutch Lever |
57341-40003-000 |
from US $7.92 |
||
|
12
|
12
09407-12402-000 CLAMP(L:120)Clamp, wiring harness Band (l:120); |
09407-12402-000 |
from US $2.24 |
||
