Rear brake Diagram Suzuki JR50
- Year
- 2006
- Model code
- JR50K6(P3/P28) K6
- Engine Capacity
- 50
- Model
- JR50
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
42300-04420-019 STAND,PROPStand, prop (black) |
42300-04420-019 |
from US $156.80 |
||
|
2
|
2
09443-14017-000 SPRING |
09443-14017-000 |
from US $4.86 |
||
|
3
|
3
09100-08274-000 BOLT(8X22)Bolt (8x22) Bolt (8x22); |
09100-08274-000 |
from US $5.17 |
||
|
4
|
4
08310-00083-000
Nut
|
08310-00083-000 |
— | ||
| replacements | |||||
|
4
|
4
08310-0008B-000 NUT |
08310-0008B-000 |
from US $0.80 |
||
|
4
|
4
08310-0008A-000 NUTNut, bead stopper |
08310-0008A-000 |
from US $0.76 |
||
|
5
|
5
43110-04410-000 PEDAL,BRAKEPedal, brake |
43110-04410-000 |
US $37.60 |
||
|
6
|
6
43181-04411-000 SPACERSpacer |
43181-04411-000 |
from US $3.20 |
||
|
7
|
7
43182-04410-000 SPRINGSpring |
43182-04410-000 |
from US $4.67 |
||
|
8
|
8
09159-10093-000 NUT |
09159-10093-000 |
from US $6.49 |
||
|
9
|
9
09160-10119-000 WASHER(10.5X22X1.6)Washer, wheel set |
09160-10119-000 |
from US $0.96 |
||
| replacement | |||||
|
9
|
9
09160-10143-000 WASHER(10.5X22X1.6) |
09160-10143-000 |
from US $0.91 |
||
