Chain guide Diagram Suzuki RM250
- Year
- 1984
- Model code
- RM250E(E/F) E
- Engine Capacity
- 250
- Model
- RM250
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
61341-14600-000
Plate outer
|
61341-14600-000 |
— | ||
|
2
|
2
61342-14500-000
Plate chain inn
|
61342-14500-000 |
— | ||
|
3
|
3
01517-06128-000
Bolt
|
01517-06128-000 |
— | ||
| replacement | |||||
|
3
|
3
01550-06127-000 BOLTBolt, rect |
01550-06127-000 |
from US $0.68 |
||
|
4
|
4
01517-06208-000
Bolt
|
01517-06208-000 |
— | ||
| replacement | |||||
|
4
|
4
01550-06207-000 BOLT |
01550-06207-000 |
from US $0.80 |
||
|
5
|
5
01517-06408-000
Bolt
|
01517-06408-000 |
— | ||
| replacement | |||||
|
5
|
5
01550-06407-000 BOLT |
01550-06407-000 |
from US $0.91 |
||
|
6
|
6
01517-06458-000
Bolt, brace
|
01517-06458-000 |
— | ||
| replacement | |||||
|
6
|
6
01550-06457-000 Bolt |
01550-06457-000 |
from US $0.91 |
||
|
7
|
7
08319-31068-000
Nut
|
08319-31068-000 |
— | ||
| replacement | |||||
|
7
|
7
08319-31067-000 NUTNut, center |
08319-31067-000 |
from US $1.44 |
||
|
8
|
8
61348-14500-000
Defense
|
61348-14500-000 |
— | ||
| replacement | |||||
|
8
|
8
61348-14510-000
DEFENSE,CHAIN GUIDE
|
61348-14510-000 |
— | ||
|
9
|
9
61349-14600-000
Pad guide
|
61349-14600-000 |
— | ||
|
10
|
10
09229-03005-000
RIVET
|
09229-03005-000 |
— | ||
