Seat Diagram Suzuki TS50
- Year
- 1994
- Model code
- TS50XAR(E4) R
- Engine Capacity
- 50
- Model
- TS50X
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
45100-34B41-H39
Seat set
Model m |
45100-34B41-H39 |
— | ||
|
1
|
1
45100-34B41-H41
Seat set
Model m |
45100-34B41-H41 |
— | ||
|
1
|
1
45100-13771-C2R
Seat set
Model r |
45100-13771-C2R |
— | ||
|
2
|
2
45119-13600-000
PLATE,SEAT HOOK FR
|
45119-13600-000 |
— | ||
|
3
|
3
45125-13600-000
Cushion, upper
Cushion, seat hook front; |
45125-13600-000 |
— | ||
|
4
|
4
08322-21066-000
Washer
|
08322-21066-000 |
— | ||
| replacement | |||||
|
4
|
4
08322-0106B-000 WASHER |
08322-0106B-000 |
from US $0.76 |
||
|
5
|
5
09324-26470-000 CUSHIONCushion, seat head; |
09324-26470-000 |
from US $0.81 |
||
|
6
|
6
09180-06035-000
Spacer (6.1x8x12)
|
09180-06035-000 |
— | ||
| replacement | |||||
|
6
|
6
09180-06249-000 SPACER(6.1X8X12)Spacer (6.1x8x12) |
09180-06249-000 |
from US $1.82 |
||
|
7
|
7
09160-06006-000
Washer
|
09160-06006-000 |
— | ||
| replacement | |||||
|
7
|
7
09160-06084-000 WASHER(6.5X18X1.6) |
09160-06084-000 |
from US $0.76 |
||
|
8
|
8
08316-26063-000
Nut
|
08316-26063-000 |
— | ||
| replacements | |||||
|
8
|
8
08316-2006A-000 NUT |
08316-2006A-000 |
from US $0.76 |
||
|
8
|
8
08316-1006B-000 NUT |
08316-1006B-000 |
from US $0.76 |
||
|
9
|
9
45210-13700-000
PLATE,SEAT LOCK STRIKER
|
45210-13700-000 |
— | ||
|
10
|
10
45213-13600-000
Cushion
Cushion, boss; |
45213-13600-000 |
— | ||
| replacement | |||||
|
10
|
10
45213-13601-000 CUSHION,SEAT LOCK(10X22X6)Cushion, boss Cushion, boss; |
45213-13601-000 |
from US $1.82 |
||
|
11
|
11
45126-13600-000
Cushion, upper
Cushion, upper; |
45126-13600-000 |
— | ||
|
12
|
12
09160-06006-000
Washer
|
09160-06006-000 |
— | ||
| replacement | |||||
|
12
|
12
09160-06084-000 WASHER(6.5X18X1.6) |
09160-06084-000 |
from US $0.76 |
||
|
13
|
13
45147-23450-000 CUSHION,SEAT FRCushion, seat head; |
45147-23450-000 |
US $1.52 |
||
|
14
|
14
45219-23450-000
Spacer seat sup
|
45219-23450-000 |
— | ||
|
15
|
15
08212-06201-000 WASHERWasher, shifting rod guide Washer; |
08212-06201-000 |
from US $0.76 |
||
|
16
|
16
08316-26063-000
Nut
|
08316-26063-000 |
— | ||
| replacements | |||||
|
16
|
16
08316-2006A-000 NUT |
08316-2006A-000 |
from US $0.76 |
||
|
16
|
16
08316-1006B-000 NUT |
08316-1006B-000 |
from US $0.76 |
||
|
17
|
17
09321-10011-000 CUSHION |
09321-10011-000 |
from US $1.52 |
||
|
18
|
18
45220-13601-000 LOCK ASSY,SEAT STRIKERLock assy, seat striker Lock assy, seat striker; |
45220-13601-000 |
from US $50.78 |
||
|
19
|
19
02112-06306-000
Screw
Model m |
02112-06306-000 |
— | ||
| replacements | |||||
|
19
|
19
02112-0630B-000 SCREWModel m |
02112-0630B-000 |
US $0.76 |
||
|
19
|
19
02112-0630A-000 SCREWModel m |
02112-0630A-000 |
from US $0.80 |
||
|
19
|
19
02112-06303-000
Screw
Screw; Model r |
02112-06303-000 |
— | ||
| replacements | |||||
|
19
|
19
02112-0630B-000 SCREWScrew; Model r |
02112-0630B-000 |
US $0.76 |
||
|
19
|
19
02112-0630A-000 SCREWScrew; Model r |
02112-0630A-000 |
from US $0.80 |
||
|
20
|
20
45280-13600-000
CABLE,SEAT LOCK
|
45280-13600-000 |
— | ||
|
21
|
21
95700-13831-000
LOCK SET,SEAT
Lock set, seat; |
95700-13831-000 |
— | ||
|
22
|
22
02112-05128-000
Screw
|
02112-05128-000 |
— | ||
| replacement | |||||
|
22
|
22
02112-05127-000 SCREWScrew, vacuum sw valve |
02112-05127-000 |
from US $0.76 |
||
|
23
|
23
08321-21057-000 Washer lockLock washer |
08321-21057-000 |
US $2.59 |
||
| replacement | |||||
|
23
|
23
08321-0105A-000 WASHER,LOCK |
08321-0105A-000 |
from US $0.76 |
||
|
24
|
24
46310-13731-000
Carrier, sports
|
46310-13731-000 |
— | ||
|
25
|
25
95700-38840-000
LOCK SET,HELMET
|
95700-38840-000 |
— | ||
