Seat Diagram Suzuki VS800 Boulevard S50
- Year
- 2008
- Model code
- VS800K8(E3/E28) K8
- Sales region
- USA/ Canada
- Engine Capacity
- 800
- Model
- VS800 (Boulevard S50)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
45100-38AA0-HW9 SEAT ASSY |
45100-38AA0-HW9 |
US $633.47 |
||
|
2
|
2
45149-43500-000 CUSHION,SEAT |
45149-43500-000 |
from US $4.80 |
||
|
3
|
3
09321-10002-000 CUSHION(11.5X22X20)Cushion Cushion; |
09321-10002-000 |
from US $1.52 |
||
|
4
|
4
09321-08009-000 CUSHIONCushion Cushion; |
09321-08009-000 |
from US $4.88 |
||
|
5
|
5
45116-38AA0-000
BRACKET,SEAT CTR,R
|
45116-38AA0-000 |
— | ||
|
6
|
6
45117-38AA0-000 BRACKET,SEAT CTR,L |
45117-38AA0-000 |
from US $13.47 |
||
|
7
|
7
01580-06167-000 BOLTBolt, seat ctr bracket; |
01580-06167-000 |
from US $4.54 |
||
|
8
|
8
09106-06117-000 BOLT(6X12)Screw, seat center Screw, seat ctr; |
09106-06117-000 |
from US $3.36 |
||
|
9
|
9
45210-38A03-000 BRACKET,SEAT FRBracket, seat front |
45210-38A03-000 |
from US $8.68 |
||
|
10
|
10
09113-06001-000 BOLT(6X16)Bolt, outer Bolt (6x16); |
09113-06001-000 |
from US $1.22 |
||
|
11
|
11
07120-0616B-000 BOLTBolt (6x16); |
07120-0616B-000 |
from US $0.91 |
||
|
12
|
12
46212-38A41-000 HANDLE,PILLION RIDER,R |
46212-38A41-000 |
US $90.53 |
||
|
13
|
13
46213-38A41-000
HANDLE,PILLION RIDER,L
|
46213-38A41-000 |
— | ||
|
14
|
14
01580-0635B-000 BOLTBolt, front (6x35); |
01580-0635B-000 |
from US $5.46 |
||
|
15
|
15
01580-0845B-000 BOLTBolt, center Bolt, rear (8x45); |
01580-0845B-000 |
from US $6.38 |
||
|
16
|
16
08316-1008B-000 NUTNut, rear; |
08316-1008B-000 |
from US $0.76 |
