Tool holder Diagram Suzuki VS800 Boulevard S50
- Year
- 2008
- Model code
- VS800K8(E3/E28) K8
- Sales region
- USA/ Canada
- Engine Capacity
- 800
- Model
- VS800 (Boulevard S50)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
47431-39A00-000
Body, tool holder
|
47431-39A00-000 |
— | ||
| replacement | |||||
|
1
|
1
47431-39A10-000 BODY,TOOL HOLDER |
47431-39A10-000 |
from US $42.69 |
||
|
2
|
2
47440-39A11-000 SPACER,TOOL HOLDER |
47440-39A11-000 |
from US $6.81 |
||
|
3
|
3
09320-10052-000 CUSHIONCushion, rear |
09320-10052-000 |
US $3.62 |
||
| replacement | |||||
|
3
|
3
09320-10079-000 Cushion |
09320-10079-000 |
from US $5.78 |
||
|
4
|
4
09160-06503-000 WasherModel k6 |
09160-06503-000 |
from US $2.15 |
||
| replacement | |||||
|
4
|
4
09160-06054-000 WASHER(6.5X22X1.6)Washer (6.5x22x1.6) Model k6 |
09160-06054-000 |
from US $1.22 |
||
|
4
|
4
09160-06158-000 WASHER(6.5X22X1.6)Model k7/k8/k9 |
09160-06158-000 |
from US $3.15 |
||
|
5
|
5
02142-0635B-000 SCREW |
02142-0635B-000 |
from US $2.38 |
||
|
6
|
6
47432-39A00-000 CAP,TOOL HOLDER |
47432-39A00-000 |
US $99.74 |
||
|
7
|
7
09139-06044-000 SCREW(6X23) |
09139-06044-000 |
from US $7.36 |
||
|
8
|
8
09148-06018-000 NUTNut, buckrest rear cover |
09148-06018-000 |
from US $1.52 |
||
|
9
|
9
09462-00008-000 BANDBand, battery Band, tool; Model k6 |
09462-00008-000 |
from US $4.80 |
||
|
9
|
9
09280-61002-000
O RING(D:3.5,ID:61)
Band, tool; Model k7/k8/k9 |
09280-61002-000 |
— | ||
| replacement | |||||
|
9
|
9
09280-61004-000 O Ring(D:3.5,id:61)Band, tool; Model k7/k8/k9 |
09280-61004-000 |
from US $4.11 |
||
|
10
|
10
09800-21013-000 TOOL ASSYModel k6 |
09800-21013-000 |
US $105 |
||
|
10
|
10
09800-21055-000
TOOL ASSY
Model k7/k8/k9 |
09800-21055-000 |
— | ||
| replacement | |||||
|
10
|
10
09800-21102-000 Tool AssyModel k7/k8/k9 |
09800-21102-000 |
from US $27.27 |
||
|
11
|
11
09812-00009-000
PLIER(150)
Plier, 150; Model k6 |
09812-00009-000 |
— | ||
