Front wheel Diagram Yamaha CW50 BW'S
- Year
- 2013
- Colour
- Black Metallic 1M (SM1M; 1306)
- Model code
- 2DW1
- Sales region
- Europe (020)
- Engine Capacity
- 50
- Color Variant
- A
- Model
- CW50E
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
2DW-F5167-00-00
Panel, Wheel 1
|
2DW-F5167-00-00 |
— | ||
|
2
|
2
2DK-F5110-00-00
Hub Assy, Front
|
2DK-F5110-00-00 |
— | ||
|
3
|
3
901-85108-04-00
Nut, Self-Locking
|
901-85108-04-00 |
— | ||
|
4
|
4
92902-10200-00 Washer, Plain |
92902-10200-00 |
US $1.18 |
||
| replacement | |||||
|
4
|
4
92990-10200-00 Washer, Plain |
92990-10200-00 |
from US $1.18 |
||
|
5
|
5
2DK-F5117-00-00
Spacer, Bearing
|
2DK-F5117-00-00 |
— | ||
|
6
|
6
93306-300Y4-00 Bearing |
93306-300Y4-00 |
from US $6.79 |
||
|
7
|
7
93102-17838-00 Oil Seal |
93102-17838-00 |
from US $5.41 |
||
|
8
|
8
3VL-F5170-10-00 Air Valve Assy |
3VL-F5170-10-00 |
from US $21.56 |
||
|
10
|
10
5ST-F5121-00-33 Plate, Brake ShoeYB FOR SM1M |
5ST-F5121-00-33 |
US $71.29 |
||
|
11
|
11
99009-20400-00 Circlip |
99009-20400-00 |
from US $1.56 |
||
|
12
|
12
93102-44833-00 Oil Seal |
93102-44833-00 |
from US $5.08 |
||
|
13
|
13
2DK-F510L-00-00
Brake Shoe Comp
|
2DK-F510L-00-00 |
— | ||
|
14
|
14
90506-12001-00 Spring, Tension |
90506-12001-00 |
from US $2.55 |
||
|
15
|
15
90506-15001-00 Spring, Tension |
90506-15001-00 |
from US $2.55 |
||
|
16
|
16
5ST-F5151-00-00 Camshaft |
5ST-F5151-00-00 |
from US $10.42 |
||
|
17
|
17
93109-14021-00 Oil Seal |
93109-14021-00 |
from US $6.11 |
||
|
18
|
18
5SU-F533A-01-00 Plate, Indicator |
5SU-F533A-01-00 |
from US $0.76 |
||
|
19
|
19
90508-28800-00 Spring, Torsion |
90508-28800-00 |
from US $2.02 |
||
|
20
|
20
5ST-F5155-00-00 Lever, Camshaft 1 |
5ST-F5155-00-00 |
from US $6.48 |
||
|
21
|
21
90101-06819-00 Bolt |
90101-06819-00 |
from US $0.31 |
||
|
22
|
22
95302-06600-00 Nut, Hexagon |
95302-06600-00 |
US $1.07 |
||
| replacement | |||||
|
22
|
22
95380-06600-00 Nut, Hexagon |
95380-06600-00 |
from US $1.18 |
||
|
23
|
23
2DK-F5138-00-00
Gear, Meter
|
2DK-F5138-00-00 |
— | ||
|
24
|
24
90201-07076-00 Washer, Plate |
90201-07076-00 |
from US $1.70 |
||
|
25
|
25
3N2-F5136-00-00 Bush |
3N2-F5136-00-00 |
from US $2.75 |
||
|
26
|
26
93104-07803-00 Oil Seal |
93104-07803-00 |
from US $1.84 |
||
|
27
|
27
2DK-F5135-00-00
Gear, Drive
|
2DK-F5135-00-00 |
— | ||
|
28
|
28
90201-20269-00 Washer, Plate |
90201-20269-00 |
from US $1.70 |
||
|
29
|
29
4X6-F5149-00-00 Clutch, Meter |
4X6-F5149-00-00 |
from US $1.24 |
||
| replacement | |||||
|
29
|
29
183-25149-00-00 Clutch, Meter |
183-25149-00-00 |
from US $2.98 |
||
|
30
|
30
932-10148-05-00
O-Ring
|
932-10148-05-00 |
— | ||
| replacement | |||||
|
30
|
30
93210-14579-00 O-Ring (26H) |
93210-14579-00 |
from US $1.52 |
||
|
31
|
31
2DW-F5183-00-00
Collar, Wheel
|
2DW-F5183-00-00 |
— | ||
|
32
|
32
956-07102-00-00 Nut, U Flange |
956-07102-00-00 |
from US $5.69 |
||
|
33
|
33
2DW-F5181-00-00
Axle, Wheel
|
2DW-F5181-00-00 |
— | ||
