Fender Diagram Yamaha CW50 BW'S Next Generation
- Year
- 1998
- Colour
- Deep Orange Candy 1 (DOC1; 0512)
- Model code
- 4YA4
- Sales region
- Europe (999)
- Engine Capacity
- 50
- Color Variant
- B
- Model
- CW50RS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
4SB-F1511-00-4B
Fender, Front
UR^BL2 |
4SB-F1511-00-4B |
— | ||
|
1
|
1
4SB-F1511-00-P8
Fender, Front
UR^YNM4 |
4SB-F1511-00-P8 |
— | ||
|
1
|
1
4SB-F1511-00-P9
Fender, Front
UR^DOC1 |
4SB-F1511-00-P9 |
— | ||
|
2
|
2
4SB-F1519-50-00
Mole, Fender
UR^YNM4 |
4SB-F1519-50-00 |
— | ||
|
2
|
2
4SB-F1519-00-00
Mole, Fender
UR^BL2/DOC1 |
4SB-F1519-00-00 |
— | ||
|
3
|
3
977-07500-16-00
Screw, Tapping(4Mv)
|
977-07500-16-00 |
— | ||
| replacement | |||||
|
3
|
3
90167-05077-00 Screw, Tapping(4Tv) |
90167-05077-00 |
from US $2.08 |
||
|
4
|
4
98907-06016-00 Screw, Bind |
98907-06016-00 |
from US $1.66 |
||
|
5
|
5
4SB-F1552-01-00
Fender, Inner
BLACK |
4SB-F1552-01-00 |
— | ||
|
6
|
6
4SB-F1553-00-00
Fender, Inner 2
BLACK |
4SB-F1553-00-00 |
— | ||
|
7
|
7
95817-06010-00 Bolt, Flange |
95817-06010-00 |
from US $1.18 |
||
|
8
|
8
90119-06052-00 Bolt, With Washer |
90119-06052-00 |
from US $1.35 |
||
| replacement | |||||
|
8
|
8
90119-06226-00 Bolt, With Washer |
90119-06226-00 |
from US $1.52 |
||
|
9
|
9
92907-06600-00 Washer, Plate |
92907-06600-00 |
from US $1.18 |
||
|
10
|
10
4SB-F1629-01-00
Guard, Mud
BLACK |
4SB-F1629-01-00 |
— | ||
| replacement | |||||
|
10
|
10
4SB-F1629-02-00
Guard,mud(Pp(Black)
BLACK |
4SB-F1629-02-00 |
— | ||
|
11
|
11
4TD-F1565-00-00
Emblem, 2
UR^BL2/DOC1 |
4TD-F1565-00-00 |
— | ||
|
11
|
11
4TD-F1565-10-00
Emblem, 2
UR^YNM4 |
4TD-F1565-10-00 |
— | ||
|
12
|
12
4UP-F152A-00-00 Emblem 2UR^BL2/DOC1 |
4UP-F152A-00-00 |
US $30.31 |
||
|
12
|
12
4UP-F152A-30-00
Emblem 3
UR^YNM4 |
4UP-F152A-30-00 |
— | ||
