Front master cylinder Diagram Yamaha CW50 BW'S
- Year
- 1999
- Model code
- 5HG1
- Sales region
- Spain (999)
- Engine Capacity
- 50
- Model
- CW50
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
4VV-F583T-11-00
Master cylinder assy
|
4VV-F583T-11-00 |
— | ||
|
02
|
02
4TD-F5867-00-00
Bracket, Master Cylinder
|
4TD-F5867-00-00 |
— | ||
|
03
|
03
4VV-F5852-00-00
Cap, Reservoir
|
4VV-F5852-00-00 |
— | ||
|
04
|
04
4TD-F6339-00-00
Boot
|
4TD-F6339-00-00 |
— | ||
|
05
|
05
4VV-H3922-10-00
Lever 2
|
4VV-H3922-10-00 |
— | ||
|
06
|
06
4VV-H3945-00-00
Bolt, Lever
|
4VV-H3945-00-00 |
— | ||
|
07
|
07
5AD-H3980-01-00 Stop Switch Asy |
5AD-H3980-01-00 |
US $34.70 |
||
| replacement | |||||
|
07
|
07
5XL-H3980-00-00 Front Stop Switch |
5XL-H3980-00-00 |
US $36.95 |
||
|
08
|
08
4TD-F5925-00-00
Clip
|
4TD-F5925-00-00 |
— | ||
|
09
|
09
4VV-F5872-01-00 Hose, Brake 1 |
4VV-F5872-01-00 |
US $161.33 |
||
| replacement | |||||
|
09
|
09
4VV-F5872-10-00 Hose, Brake 1 |
4VV-F5872-10-00 |
US $161.33 |
||
|
10
|
10
90401-10X01-00 Bolt, Union |
90401-10X01-00 |
US $7.22 |
||
|
11
|
11
90201-10X03-00 Washer, Plain |
90201-10X03-00 |
from US $4.68 |
||
|
12
|
12
4TD-F5924-00-00
Pin, Pad
|
4TD-F5924-00-00 |
— | ||
|
13
|
13
4TD-F5856-00-00
Piston, Master Cylinder
|
4TD-F5856-00-00 |
— | ||
|
14
|
14
4VV-F5870-00-00
Master Cylinder Sub Assy
Non representado |
4VV-F5870-00-00 |
— | ||
