Front fender Diagram Yamaha PW80 Zinger
- Year
- 1993
- Colour
- Purplish White Solid 1 (PW S1; 0206)
- Model code
- 4BC3
- Sales region
- France (999)
- Engine Capacity
- 80
- Model
- PW80
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
3RV-21511-00-00
Fender, Front
|
3RV-21511-00-00 |
— | ||
|
02
|
02
90159-06033-00 Screw, With Washer |
90159-06033-00 |
from US $1.70 |
||
| replacements | |||||
|
02
|
02
98507-06016-00 Screw, Pan Head |
98507-06016-00 |
from US $1.52 |
||
|
02
|
02
901-59060-60-00
Screw, With Washer
|
901-59060-60-00 |
— | ||
|
03
|
03
901-19060-43-00
Bolt, With Washer
|
901-19060-43-00 |
— | ||
| replacement | |||||
|
03
|
03
901-19062-42-00 Bolt, With Washer |
901-19062-42-00 |
from US $1.52 |
||
|
04
|
04
3RV-21659-10-00
Label, safety
|
3RV-21659-10-00 |
— | ||
|
05
|
05
99244-00020-00 Emblem, Yamaha |
99244-00020-00 |
from US $8.64 |
||
| replacement | |||||
|
05
|
05
99244-00080-00 Emblem, Yamaha |
99244-00080-00 |
from US $8.74 |
||
