Tachometer gear Diagram Yamaha RD
- Year
- 1982
- Model code
- 12G
- Sales region
- Europe (General) (999)
- Engine Capacity
- 80
- Model
- RD80
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
237-17861-00-00
Axle, Drive Gear
|
237-17861-00-00 |
— | ||
| replacement | |||||
|
01
|
01
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
02
|
02
353-17831-01-00
Gear, Drive (353-17831-00)
|
353-17831-01-00 |
— | ||
|
03
|
03
248-17837-00-00 Shim |
248-17837-00-00 |
US $5.45 |
||
|
04
|
04
353-17810-00-00
Housing Assembly, Tach (214-178
|
353-17810-00-00 |
— | ||
|
05
|
05
93210-13016-00 O-Ring |
93210-13016-00 |
from US $1.98 |
||
|
06
|
06
214-17841-01-00
Gear, Driven
|
214-17841-01-00 |
— | ||
|
07
|
07
214-17812-00-00
Stopper
|
214-17812-00-00 |
— | ||
| replacement | |||||
|
07
|
07
5U7-17812-00-00
Stopper
|
5U7-17812-00-00 |
— | ||
|
08
|
08
97301-06010-00 Bolt |
97301-06010-00 |
from US $1.56 |
||
| replacement | |||||
|
08
|
08
97017-06010-00 Bolt |
97017-06010-00 |
from US $1.34 |
||
