Starter Diagram Yamaha RT180
- Year
- 1990
- Sales region
- USA
- Engine Capacity
- 180
- Model
- RT180
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
4F2-15660-01-00 Kick Axle Assembly |
4F2-15660-01-00 |
from US $83.72 |
||
|
2
|
2
1W1-15641-00-00 Gear, Kick (27T)27T |
1W1-15641-00-00 |
from US $43.52 |
||
|
3
|
3
90468-26048-00 Clip |
90468-26048-00 |
from US $1.84 |
||
|
4
|
4
401-15676-00-00 Cover, Spring |
401-15676-00-00 |
from US $2.98 |
||
|
5
|
5
90508-26450-00 Spring, Torsion |
90508-26450-00 |
from US $3.98 |
||
|
6
|
6
1W1-15666-00-00 Spacer |
1W1-15666-00-00 |
from US $11.05 |
||
|
7
|
7
5L9-E5651-00-00 Gear, Kick Idle (25T)25T |
5L9-E5651-00-00 |
US $63.97 |
||
| replacement | |||||
|
7
|
7
525-15651-00-00 Gear, Kick Idle (25T)25T |
525-15651-00-00 |
from US $44.76 |
||
|
8
|
8
3V9-E7417-00-00 Shim 1 |
3V9-E7417-00-00 |
US $0.85 |
||
|
9
|
9
934-40150-12-00
Circlip
|
934-40150-12-00 |
— | ||
| replacement | |||||
|
9
|
9
99009-15400-00 Circlip(1Ar) |
99009-15400-00 |
from US $1.07 |
||
|
10
|
10
2TW-E5620-00-00
Kick Crank Assembly
|
2TW-E5620-00-00 |
— | ||
| replacements | |||||
|
10
|
10
ACN-CK2TW-10-00
UNDER BRACKET COMP
|
ACN-CK2TW-10-00 |
— | ||
|
10
|
10
2TW-E5620-10-00
Ekt Kick Crank Assy
|
2TW-E5620-10-00 |
— | ||
|
11
|
11
91316-08025-00 Bolt |
91316-08025-00 |
from US $1.07 |
||
| replacement | |||||
|
11
|
11
913-17080-25-00 Bolt |
913-17080-25-00 |
from US $1.07 |
||
|
12
|
12
93101-17062-00 Oil Seal |
93101-17062-00 |
from US $8.22 |
||
