Starter Diagram Yamaha SDR 200
- Year
- 1987
- Colour
- Melting Green (MELG; 00T8)
- Model code
- 2TV
- Sales region
- Japan (010)
- Engine Capacity
- 200
- Color Variant
- B
- Model
- SDR200
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
2TV-15660-00-00
Kick Axle Assy
|
2TV-15660-00-00 |
— | ||
|
2
|
2
10V-15641-00-00 Gear, Kickギア，キツク ; ２３Ｔ |
10V-15641-00-00 |
from US $75.02 |
||
|
3
|
3
90468-26048-00 Clip |
90468-26048-00 |
from US $1.94 |
||
|
4
|
4
90201-202F9-00 Washer, Plate |
90201-202F9-00 |
from US $1.98 |
||
|
5
|
5
90508-26667-00 Spring, Torsion |
90508-26667-00 |
from US $6.24 |
||
|
6
|
6
10V-15666-00-00
Guide, Spring
|
10V-15666-00-00 |
— | ||
| replacement | |||||
|
6
|
6
5HP-15664-00-00
Guide, Spring
|
5HP-15664-00-00 |
— | ||
|
7
|
7
10V-15651-00-00 Gear, Kick Idleギア，キツクアイドル ; ２９Ｔ |
10V-15651-00-00 |
from US $92.71 |
||
|
8
|
8
90201-154E8-00 Washer, Plate (4L0) |
90201-154E8-00 |
from US $1.84 |
||
|
9
|
9
934-40150-12-00
Circlip
|
934-40150-12-00 |
— | ||
| replacement | |||||
|
9
|
9
99009-15400-00 Circlip(1Ar) |
99009-15400-00 |
from US $1.18 |
||
|
10
|
10
2TV-15620-00-00
Kick Crank Assy
|
2TV-15620-00-00 |
— | ||
| replacement | |||||
|
10
|
10
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
11
|
11
156-15618-01-00 Cover, Kick Lever．カバ−，キツクレバ−; |
156-15618-01-00 |
from US $4.58 |
||
|
12
|
12
901-79122-44-00
Nut
|
901-79122-44-00 |
— | ||
| replacement | |||||
|
12
|
12
90179-12659-00 Nut |
90179-12659-00 |
from US $1.81 |
||
|
13
|
13
931-02203-09-00 Oil Seal (25Y)オイルシ−ル; |
931-02203-09-00 |
from US $10.69 |
||
