Shift Cam & Fork Diagram Yamaha TDR125
- Year
- 1991
- Colour
- Classic Black (CBA; 00KH)
- Model code
- 3SH1
- Sales region
- Europe (General) (999)
- Engine Capacity
- 125
- Model
- TDR125
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
3SH-F6111-00-00
Handlebar
|
3SH-F6111-00-00 |
— | ||
|
02
|
02
3SH-F6280-00-00
Rear View Mirror Assy(Left)
|
3SH-F6280-00-00 |
— | ||
| replacement | |||||
|
02
|
02
5CH-F6280-00-00
Rear View Mirror As
|
5CH-F6280-00-00 |
— | ||
|
03
|
03
3SH-F6290-00-00
Rear View Mirror Assy (Right)
|
3SH-F6290-00-00 |
— | ||
| replacement | |||||
|
03
|
03
5CH-F6290-00-00
Rear View Mirror As
|
5CH-F6290-00-00 |
— | ||
|
04
|
04
322-26243-00-00 Tube, Throttle Guide |
322-26243-00-00 |
from US $12.61 |
||
| replacement | |||||
|
04
|
04
22W-26243-00-00 Tube, Throttle Guide |
22W-26243-00-00 |
from US $15.12 |
||
|
05
|
05
3SH-F6242-00-00
Grip (Right)
|
3SH-F6242-00-00 |
— | ||
|
06
|
06
1M1-26249-01-00 Ring, Leaf |
1M1-26249-01-00 |
from US $3.68 |
||
|
07
|
07
3SH-F6241-00-00
Grip
|
3SH-F6241-00-00 |
— | ||
| replacement | |||||
|
07
|
07
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
08
|
08
3SH-F6301-00-00
Throttle Cable Assy
|
3SH-F6301-00-00 |
— | ||
|
09
|
09
3BN-26335-00-00 Cable, clutch |
3BN-26335-00-00 |
US $44.90 |
||
|
10
|
10
901-23080-46-00 Bolt |
901-23080-46-00 |
from US $3.74 |
||
| replacement | |||||
|
10
|
10
901-23080-02-00 Bolt |
901-23080-02-00 |
from US $3.74 |
||
|
11
|
11
90179-08048-00
Nut
|
90179-08048-00 |
— | ||
|
12
|
12
1E6-26342-00-00 Boot, Cable |
1E6-26342-00-00 |
from US $15.68 |
||
|
13
|
13
5X2-26281-00-00 Cap, Grip Upper |
5X2-26281-00-00 |
from US $21.82 |
||
|
14
|
14
322-26282-00-00 Cap, Grip Under |
322-26282-00-00 |
from US $14.45 |
||
|
15
|
15
5X2-2628H-01-00 Cap, Wire |
5X2-2628H-01-00 |
from US $9.57 |
||
|
16
|
16
987-06040-12-00
Screw, Flat Head
|
987-06040-12-00 |
— | ||
| replacement | |||||
|
16
|
16
98707-04012-00 Screw, Flat Head |
98707-04012-00 |
from US $1.52 |
||
|
17
|
17
98506-05012-00 Screw, Pan Head |
98506-05012-00 |
from US $1.21 |
||
| replacements | |||||
|
17
|
17
98517-05012-00 Screw, Pan Head |
98517-05012-00 |
from US $1.21 |
||
|
17
|
17
976-06051-12-00
Screw, Pan Head With Washer
|
976-06051-12-00 |
— | ||
