Front brake caliper Diagram Yamaha TY250 SCOTTISH
- Year
- 1995
- Colour
- Purplish White Solid 1 (PW S1; 0206)
- Model code
- 4ML1
- Sales region
- Japan (010)
- Engine Capacity
- 250
- Color Variant
- A
- Model
- TY250
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
4ML-2582T-00-00
Disc, Brake (Left)
デイスク，ブレーキ ; レフト |
4ML-2582T-00-00 |
— | ||
|
2
|
2
90101-06744-00
Bolt
|
90101-06744-00 |
— | ||
| replacement | |||||
|
2
|
2
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
3
|
3
92907-06200-00 Washer(6Ta) |
92907-06200-00 |
from US $1.07 |
||
|
4
|
4
4ML-2580T-00-00
Caliper Assy (Left)
キヤリパアセンブリ ; レフト; 参照 |
4ML-2580T-00-00 |
— | ||
|
5
|
5
4ML-W0057-00-00 Piston Assy, Caliper．ピストンアセンブリ，キヤリパ; |
4ML-W0057-00-00 |
US $101.41 |
||
|
6
|
6
4ML-W0047-00-00 Caliper Seal Kit．．キヤリパシールキツト; |
4ML-W0047-00-00 |
from US $34.14 |
||
|
7
|
7
56A-25937-00-00 Boot 2．ブーツ ２; 参照 |
56A-25937-00-00 |
from US $14.03 |
||
|
8
|
8
5R2-25937-00-00 Boot 2．ブーツ ２; 参照 |
5R2-25937-00-00 |
from US $19.55 |
||
|
9
|
9
4ML-W0045-00-00 Brake Pad Kit．ブレーキパツドキツト; |
4ML-W0045-00-00 |
US $70.99 |
||
|
10
|
10
56A-25919-10-00 Support, Pad．サポート，パツド; |
56A-25919-10-00 |
from US $20.26 |
||
|
11
|
11
56A-25919-00-00 Support, Pad．サポート，パツド; |
56A-25919-00-00 |
from US $20.26 |
||
|
13
|
13
51L-W0048-00-00
Bleed Screw Kit
．ブリードスクリユキツト; |
51L-W0048-00-00 |
— | ||
| replacement | |||||
|
13
|
13
15B-W0048-00-00 Bleed Screw Kit．ブリードスクリユキツト; |
15B-W0048-00-00 |
from US $8.08 |
||
|
14
|
14
34X-25845-00-00 Cap, Indicator．キヤツプ，インジケータ; |
34X-25845-00-00 |
from US $7.23 |
||
|
15
|
15
90105-08467-00 Bolt, Flangeボルト，ワツシヤベースドヘツド; |
90105-08467-00 |
US $1.07 |
||
| replacements | |||||
|
15
|
15
95817-08025-00 Bolt, Flangeボルト，ワツシヤベースドヘツド; |
95817-08025-00 |
from US $1.07 |
||
|
15
|
15
999-99999-99-00
Not Available
ボルト，ワツシヤベースドヘツド; |
999-99999-99-00 |
— | ||
