Front fork Diagram Yamaha TZ125
- Year
- 1995
- Colour
- White (WW; 0036)
- Model code
- 4JT2
- Sales region
- North America (999)
- Engine Capacity
- 125
- Model
- TZ125
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
4JT-23102-10-00
Front Fork Assy (L.h)
|
4JT-23102-10-00 |
— | ||
|
02
|
02
4JT-23136-10-00
Tube, Outer 2
|
4JT-23136-10-00 |
— | ||
|
03
|
03
4A1-23156-00-00 Ring, Snap |
4A1-23156-00-00 |
from US $4.39 |
||
|
04
|
04
4ES-23145-00-00 Oil Seal |
4ES-23145-00-00 |
from US $8.94 |
||
|
05
|
05
5K5-23149-00-00 Washer, Spring Upper |
5K5-23149-00-00 |
from US $6.94 |
||
|
06
|
06
4JT-23110-00-00
Inner Tube Comp.1
|
4JT-23110-00-00 |
— | ||
|
07
|
07
4JT-23170-00-00
Cylinder Comp., Front Fork
|
4JT-23170-00-00 |
— | ||
| replacement | |||||
|
07
|
07
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
08
|
08
2K8-23158-L0-00 Gasket |
2K8-23158-L0-00 |
from US $12.47 |
||
|
09
|
09
3LC-23181-00-00 Bolt, Hexagon Socket Head |
3LC-23181-00-00 |
from US $11.76 |
||
|
10
|
10
3XJ-23357-L0-00 Nut |
3XJ-23357-L0-00 |
from US $1.13 |
||
|
11
|
11
4JT-23141-10-00 Spring, Front Fork |
4JT-23141-10-00 |
US $29.68 |
||
|
12
|
12
4JT-23118-00-00
Spacer
|
4JT-23118-00-00 |
— | ||
|
13
|
13
3YL-2333K-00-00
Guide
|
3YL-2333K-00-00 |
— | ||
| replacement | |||||
|
13
|
13
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
14
|
14
4V4-23188-L0-00 O-Ring |
4V4-23188-L0-00 |
from US $8.36 |
||
|
15
|
15
3TJ-23111-10-00
Bolt, Cap
|
3TJ-23111-10-00 |
— | ||
|
16
|
16
1WG-23128-00-00
Bolt, Hexagon Socket Head
|
1WG-23128-00-00 |
— | ||
| replacement | |||||
|
16
|
16
91314-08040-00 Bolt, Hexagon Socket Head |
91314-08040-00 |
from US $3.26 |
||
|
17
|
17
4JT-23103-10-00
Front Fork Assy (R.h)
|
4JT-23103-10-00 |
— | ||
|
18
|
18
4JT-23136-10-00
Tube, Outer 2
|
4JT-23136-10-00 |
— | ||
|
19
|
19
4A1-23156-00-00 Ring, Snap |
4A1-23156-00-00 |
from US $4.39 |
||
|
20
|
20
4ES-23145-00-00 Oil Seal |
4ES-23145-00-00 |
from US $8.94 |
||
|
21
|
21
5K5-23149-00-00 Washer, Spring Upper |
5K5-23149-00-00 |
from US $6.94 |
||
|
22
|
22
4JT-23120-00-00
Inner Tube Comp.2
|
4JT-23120-00-00 |
— | ||
|
23
|
23
4JT-23170-00-00
Cylinder Comp., Front Fork
|
4JT-23170-00-00 |
— | ||
| replacement | |||||
|
23
|
23
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
24
|
24
2K8-23158-L0-00 Gasket |
2K8-23158-L0-00 |
from US $12.47 |
||
|
25
|
25
3LC-23181-00-00 Bolt, Hexagon Socket Head |
3LC-23181-00-00 |
from US $11.76 |
||
|
26
|
26
3XJ-23357-L0-00 Nut |
3XJ-23357-L0-00 |
from US $1.13 |
||
|
27
|
27
4JT-23141-10-00 Spring, Front Fork |
4JT-23141-10-00 |
US $29.68 |
||
|
28
|
28
4JT-23118-00-00
Spacer
|
4JT-23118-00-00 |
— | ||
|
29
|
29
3YL-2333K-00-00
Guide
|
3YL-2333K-00-00 |
— | ||
| replacement | |||||
|
29
|
29
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
30
|
30
4V4-23188-L0-00 O-Ring |
4V4-23188-L0-00 |
from US $8.36 |
||
|
31
|
31
3TJ-23111-10-00
Bolt, Cap
|
3TJ-23111-10-00 |
— | ||
|
32
|
32
1WG-23128-00-00
Bolt, Hexagon Socket Head
|
1WG-23128-00-00 |
— | ||
| replacement | |||||
|
32
|
32
91314-08040-00 Bolt, Hexagon Socket Head |
91314-08040-00 |
from US $3.26 |
||
|
33
|
33
4JT-23340-00-00
Under Bracket Comp
|
4JT-23340-00-00 |
— | ||
| replacement | |||||
|
33
|
33
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
34
|
34
91316-10030-00 Bolt |
91316-10030-00 |
from US $4.25 |
||
| replacement | |||||
|
34
|
34
91317-10030-00 Bolt, Socket |
91317-10030-00 |
from US $4.25 |
||
|
35
|
35
4JT-23435-00-00
Crown, Handle
|
4JT-23435-00-00 |
— | ||
|
36
|
36
3TC-23471-00-00
Bolt
|
3TC-23471-00-00 |
— | ||
