Steering handle & cable Diagram Yamaha XP500 T-MAX
- Year
- 2001
- Colour
- Silver 1 (S1; 0755)
- Model code
- 5GJ4
- Sales region
- Japan (010)
- Engine Capacity
- 500
- Color Variant
- B
- Model
- XP500
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5GJ-26110-10-00 Handle Compハンドルコンプリート; |
5GJ-26110-10-00 |
US $97.10 |
||
|
2
|
2
4YR-26241-01-00 Grip (Left) |
4YR-26241-01-00 |
from US $15.34 |
||
| replacements | |||||
|
2
|
2
4YR-26241-02-00
Grip (Left)
|
4YR-26241-02-00 |
— | ||
|
2
|
2
4YR-26241-03-00 Grip |
4YR-26241-03-00 |
from US $9.10 |
||
|
3
|
3
5GJ-26240-00-00 Grip Assy |
5GJ-26240-00-00 |
US $30.18 |
||
| replacement | |||||
|
3
|
3
5GJ-26240-01-00 Grip Assy |
5GJ-26240-01-00 |
US $30.18 |
||
|
4
|
4
5GJ-26246-00-00 End, Grip |
5GJ-26246-00-00 |
from US $13.82 |
||
|
5
|
5
5GJ-26311-03-00
Cable, Throttle 1
ケーブル，スロツトル １; |
5GJ-26311-03-00 |
— | ||
|
6
|
6
5GJ-26312-03-00
Cable, Throttle 2
ケーブル，スロツトル ２; |
5GJ-26312-03-00 |
— | ||
|
7
|
7
985-07050-10-00
Screw, Pan Head
|
985-07050-10-00 |
— | ||
| replacement | |||||
|
7
|
7
985-17050-10-00 Screw, Pan Head |
985-17050-10-00 |
from US $1.36 |
||
|
8
|
8
5GJ-26144-01-00 Cover, Handlebar Lower 1カバー，ハンドルバーロワ １; |
5GJ-26144-01-00 |
US $39.38 |
||
| replacement | |||||
|
8
|
8
5GJ-26144-02-00 Cover, Handlebar Lower 1カバー，ハンドルバーロワ １; |
5GJ-26144-02-00 |
US $39.38 |
||
|
9
|
9
90159-05028-00 Screw, With Washer |
90159-05028-00 |
from US $2.83 |
||
| replacement | |||||
|
9
|
9
90159-05121-00 Screw, With Washer |
90159-05121-00 |
from US $3.05 |
||
|
10
|
10
5GJ-26143-00-00 Cover, Handle Upper 1カバー，ハンドルバーアツパ １; |
5GJ-26143-00-00 |
US $28.94 |
||
|
11
|
11
5GJ-26219-00-00 Emblem |
5GJ-26219-00-00 |
US $56.92 |
||
|
12
|
12
90167-05080-00 Screw, Tapping |
90167-05080-00 |
from US $1.66 |
||
|
13
|
13
90167-05079-00 Screw, Tapping |
90167-05079-00 |
from US $1.66 |
||
|
14
|
14
901-83050-42-00 Nut, Spring |
901-83050-42-00 |
from US $1.52 |
||
