Rear wheel Diagram Yamaha XVS1100 V-Star Midnight Custom
- Year
- 2005
- Model code
- 5PBR
- Sales region
- USA
- Engine Capacity
- 1100
- Model
- XVS1100 (V-Star Midnight Custom)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5EL-25311-00-00 Hub, Rear |
5EL-25311-00-00 |
from US $372.62 |
||
|
2
|
2
90387-173M5-00 Collar |
90387-173M5-00 |
from US $12.04 |
||
|
3
|
3
933-06203-48-00 Bearing |
933-06203-48-00 |
from US $17.86 |
||
|
4
|
4
93306-30317-00 Bearing |
93306-30317-00 |
from US $27.74 |
||
|
5
|
5
93102-25044-00 Oil Seal |
93102-25044-00 |
from US $5.06 |
||
|
6
|
6
16G-25366-01-00 Clutch, Hub |
16G-25366-01-00 |
from US $128.35 |
||
|
7
|
7
5EL-25364-00-00 Damper |
5EL-25364-00-00 |
from US $35.42 |
||
|
8
|
8
93210-48530-00 O-Ring |
93210-48530-00 |
from US $4.39 |
||
|
9
|
9
93210-59531-00 O-Ring |
93210-59531-00 |
from US $5.24 |
||
|
10
|
10
16G-25412-00-00 Washer |
16G-25412-00-00 |
from US $9.63 |
||
|
11
|
11
901-70102-19-00
Nut
|
901-70102-19-00 |
— | ||
| replacement | |||||
|
11
|
11
90170-10011-00 Nut |
90170-10011-00 |
from US $1.52 |
||
|
12
|
12
93210-57428-00 O-Ring |
93210-57428-00 |
from US $5.68 |
||
|
13
|
13
5KS-25304-00-00 Spoke Set, Rear |
5KS-25304-00-00 |
from US $175.46 |
||
|
14
|
14
94445-15607-00 Rim (Mt4.50-15M/c) |
94445-15607-00 |
from US $418.75 |
||
|
15
|
15
3HT-25398-00-00 Balancer, Wheel (15G)15G UN |
3HT-25398-00-00 |
from US $8.08 |
||
|
16
|
16
941-17150-8W-00 Tire (170/80-15 M/c 77S K555)170/80-15 M/C 77S K555 UR DUNLOP |
941-17150-8W-00 |
US $272.21 |
||
|
16
|
16
941-17150-08-00 Tire (170/80-15 M/c 77S G546)170/80-15 M/C 77S G546 UR BRIDGESTONE |
941-17150-08-00 |
US $237.26 |
||
|
17
|
17
942-17152-98-00
Tube(4Tr)
170/80-15 M/C PV78 UR BRIDGESTONE |
942-17152-98-00 |
— | ||
|
17
|
17
942-17152-99-00
Tube (170/80-15 M/c Pv78)
170/80-15 M/C PV78 UR DUNLOP |
942-17152-99-00 |
— | ||
| replacements | |||||
|
17
|
17
999-99999-99-00
Not Available
170/80-15 M/C PV78 UR DUNLOP |
999-99999-99-00 |
— | ||
|
17
|
17
942-17152-98-00
Tube(4Tr)
170/80-15 M/C PV78 UR DUNLOP |
942-17152-98-00 |
— | ||
|
18
|
18
94317-15181-00 Band, Rim (4.50-15)4.50-15 UR BRIDGESTONE |
94317-15181-00 |
from US $5.13 |
||
|
18
|
18
94317-15180-00 Band, Rim (55-15)55-15 UR DUNLOP |
94317-15180-00 |
from US $3.76 |
||
| replacement | |||||
|
18
|
18
94317-15181-00 Band, Rim (4.50-15)55-15 UR DUNLOP |
94317-15181-00 |
from US $5.13 |
||
|
19
|
19
5EL-25381-00-00 Axle, Wheel |
5EL-25381-00-00 |
from US $62.58 |
||
| replacement | |||||
|
19
|
19
5EL-25381-10-00 Axle, Wheel |
5EL-25381-10-00 |
from US $62.58 |
||
|
20
|
20
90201-160T2-00 Washer, Plate(3Ld) |
90201-160T2-00 |
from US $9.21 |
||
|
21
|
21
95604-16200-00 Nut, U Flange |
95604-16200-00 |
from US $18.70 |
||
|
22
|
22
90387-177Y4-00 Collar |
90387-177Y4-00 |
from US $9.57 |
||
|
23
|
23
4H7-25377-00-00 Collar, Wheel |
4H7-25377-00-00 |
from US $5.24 |
||
