Front master cylinder Diagram Yamaha XVS650 V-Star Midnight Custom
- Year
- 2007
- Model code
- 5S11
- Sales region
- USA
- Базовая модель
- XVS65WC-M
- Engine Capacity
- 650
- Model
- XVS650 (V-Star Midnight Custom)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
4TR-25870-10-00 Master Cylinder Sub Assy |
4TR-25870-10-00 |
from US $176.84 |
||
| replacement | |||||
|
1
|
1
3D8-25870-01-00 Master Cylinder Sub Assy |
3D8-25870-01-00 |
from US $176.84 |
||
|
2
|
2
4TR-25852-10-00 Cap, Reservoir |
4TR-25852-10-00 |
from US $25.07 |
||
|
3
|
3
4BH-25815-00-00 Seal, Piston |
4BH-25815-00-00 |
from US $21.82 |
||
|
4
|
4
36Y-2589H-00-00 Screw, Flat Head |
36Y-2589H-00-00 |
from US $1.35 |
||
| replacement | |||||
|
4
|
4
98707-04012-00 Screw, Flat Head |
98707-04012-00 |
from US $1.34 |
||
|
5
|
5
4BH-25854-02-00 Diaphragm, Reservoir |
4BH-25854-02-00 |
from US $22.81 |
||
|
6
|
6
2KR-W0041-00-00
Cylinder Kit, Master
|
2KR-W0041-00-00 |
— | ||
| replacement | |||||
|
6
|
6
2KR-25807-00-00 Cylinder Kit, Master |
2KR-25807-00-00 |
from US $46.70 |
||
|
7
|
7
4TR-25867-10-00 Bracket, Master Cylinder |
4TR-25867-10-00 |
from US $19.98 |
||
|
8
|
8
91314-06025-00 Bolt, Hexagon Socket Head |
91314-06025-00 |
from US $1.56 |
||
|
9
|
9
5KP-25872-10-00 Hose, Brake 1 |
5KP-25872-10-00 |
from US $99.75 |
||
|
10
|
10
90401-10020-00 Bolt, Union |
90401-10020-00 |
from US $2.69 |
||
|
11
|
11
90430-10005-00 Gasket |
90430-10005-00 |
from US $1.56 |
||
