Flexible pipe Diagram Yamaha YA50 Axis 50
- Year
- 1996
- Model code
- 4MJ7
- Sales region
- General (999)
- Engine Capacity
- 50
- Model
- YA50
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
3WG-E4610-00-00
Exhaust Pipe Assy 1
|
3WG-E4610-00-00 |
— | ||
| replacement | |||||
|
01
|
01
3WG-X4610-00-00
Exhaust Pipe Assy
|
3WG-X4610-00-00 |
— | ||
|
02
|
02
4MJ-E4445-00-00 Grommet |
4MJ-E4445-00-00 |
from US $2.83 |
||
|
03
|
03
4MJ-E4779-00-00 Collar |
4MJ-E4779-00-00 |
US $4.39 |
||
| replacement | |||||
|
03
|
03
5EU-E4779-00-00 Collar |
5EU-E4779-00-00 |
from US $4.39 |
||
|
04
|
04
3WG-E4613-00-00 Gasket, Exhaust Pipe |
3WG-E4613-00-00 |
US $8.36 |
||
| replacement | |||||
|
04
|
04
5AD-E4613-00-00 Gasket, Exhaust Pi |
5AD-E4613-00-00 |
US $8.36 |
||
|
05
|
05
90149-06113-00 Screw, Hexagon |
90149-06113-00 |
from US $1.84 |
||
| replacement | |||||
|
05
|
05
90153-06061-00 Screw, Hexagon |
90153-06061-00 |
from US $1.84 |
||
|
06
|
06
95816-08020-00 Bolt, Flange |
95816-08020-00 |
from US $0.85 |
||
| replacement | |||||
|
06
|
06
958-17080-20-00 Bolt, Flange |
958-17080-20-00 |
from US $0.85 |
||
|
07
|
07
95816-08075-00 Bolt, Flange |
95816-08075-00 |
US $1.98 |
||
| replacement | |||||
|
07
|
07
95817-08075-00 Bolt, Flange |
95817-08075-00 |
from US $1.98 |
||
|
08
|
08
3WG-E4718-00-00
Protector, Muffler 1
|
3WG-E4718-00-00 |
— | ||
|
09
|
09
3WG-E4766-00-00
Washer, Protector
|
3WG-E4766-00-00 |
— | ||
|
10
|
10
929-02062-00-00
Washer, Plain
|
929-02062-00-00 |
— | ||
| replacement | |||||
|
10
|
10
92990-06200-00 Washer, Plain |
92990-06200-00 |
from US $1.07 |
||
|
11
|
11
98906-06016-00 Screw, Bind |
98906-06016-00 |
from US $1.56 |
||
| replacement | |||||
|
11
|
11
98907-06016-00 Screw, Bind |
98907-06016-00 |
from US $1.56 |
||
|
12
|
12
90480-12237-00 Grommet |
90480-12237-00 |
from US $1.35 |
||
|
13
|
13
90387-060G7-00 Collar(47X) |
90387-060G7-00 |
from US $1.35 |
||
|
14
|
14
3WG-E4766-10-00
Washer, Protector
|
3WG-E4766-10-00 |
— | ||
|
15
|
15
90387-088A9-00
Collar
|
90387-088A9-00 |
— | ||
|
16
|
16
3WG-F7416-10-00
Bolt, Footrest
|
3WG-F7416-10-00 |
— | ||
