Fender Diagram Yamaha YA50 Forte 50
- Year
- 1994
- Colour
- Frost Silver (FRS; 009G)
- Model code
- 4PC1
- Sales region
- General (999)
- Engine Capacity
- 50
- Model
- YA50
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
4PC-X1511-00-9G
Fender, Front
(ur frost silver) |
4PC-X1511-00-9G |
— | ||
|
01
|
01
4PC-X1511-00-P1
Fender, Front
(ur spanish dark green, cockta) |
4PC-X1511-00-P1 |
— | ||
| replacement | |||||
|
01
|
01
4PC-X1511-00-Q2
Fender Front
(ur spanish dark green, cockta) |
4PC-X1511-00-Q2 |
— | ||
|
02
|
02
4PC-F1571-00-00
Graphic, Front Fender 1
(ur for frs) |
4PC-F1571-00-00 |
— | ||
|
02
|
02
4PC-F1571-10-00
Graphic, Front Fender 1
(ur for sdgc1) |
4PC-F1571-10-00 |
— | ||
|
03
|
03
4PC-F1572-00-00
Graphic, Front Fender 2
(ur for frs) |
4PC-F1572-00-00 |
— | ||
|
03
|
03
4PC-F1572-10-00
Graphic, Front Fender 2
(ur for sdgc1) |
4PC-F1572-10-00 |
— | ||
|
04
|
04
4CU-F8315-00-00
Emblem
|
4CU-F8315-00-00 |
— | ||
|
05
|
05
4PC-F1552-00-00
Fender, Inner
|
4PC-F1552-00-00 |
— | ||
|
06
|
06
3WG-F1553-00-00
Fender, Inner 2
|
3WG-F1553-00-00 |
— | ||
|
07
|
07
958-07060-12-00
Bolt, Flange
|
958-07060-12-00 |
— | ||
| replacement | |||||
|
07
|
07
958-17060-12-00 Bolt, Flange |
958-17060-12-00 |
from US $1.07 |
||
|
08
|
08
901-19060-44-00
Bolt, With Washer
|
901-19060-44-00 |
— | ||
| replacement | |||||
|
08
|
08
901-19062-42-00 Bolt, With Washer |
901-19062-42-00 |
from US $1.35 |
||
|
09
|
09
90163-05006-00 Screw, Tapping |
90163-05006-00 |
from US $1.84 |
||
| replacement | |||||
|
09
|
09
90167-05077-00 Screw, Tapping(4Tv) |
90167-05077-00 |
from US $1.84 |
||
