Front fender Diagram Yamaha YA50 Axis 50
- Year
- 1995
- Colour
- Black Solid 1 (BS1; 005C)
- Model code
- 4SC1
- Sales region
- Italy (999)
- Engine Capacity
- 50
- Model
- YA50
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
4JL-X2151-30-00
Fender, Front
Ur red |
4JL-X2151-30-00 |
— | ||
|
01
|
01
4JL-X2151-60-4B
Fender, Front
Ur black |
4JL-X2151-60-4B |
— | ||
|
02
|
02
4JL-F1569-00-00
Graphic 1
Ur black |
4JL-F1569-00-00 |
— | ||
|
02
|
02
4JL-F1569-20-00
Graphic 1
Ur red |
4JL-F1569-20-00 |
— | ||
|
03
|
03
4JL-F1579-00-00
Graphic 2
Ur blck |
4JL-F1579-00-00 |
— | ||
|
03
|
03
4JL-F1579-20-00
Graphic 2
Ur red |
4JL-F1579-20-00 |
— | ||
|
04
|
04
4DY-F1737-70-00
Emblem
|
4DY-F1737-70-00 |
— | ||
|
05
|
05
4JL-F1552-00-00
Fender, Inner
|
4JL-F1552-00-00 |
— | ||
|
06
|
06
3GF-F1553-00-00
Fender, Inner 2
|
3GF-F1553-00-00 |
— | ||
| replacement | |||||
|
06
|
06
3GF-F1553-01-00
Fender, Inner 2
|
3GF-F1553-01-00 |
— | ||
|
07
|
07
90159-06812-00 Screw, With Washer |
90159-06812-00 |
from US $3.47 |
||
|
08
|
08
958-07060-12-00
Bolt, Flange
|
958-07060-12-00 |
— | ||
| replacement | |||||
|
08
|
08
958-17060-12-00 Bolt, Flange |
958-17060-12-00 |
from US $1.39 |
||
|
09
|
09
901-19068-21-00
Bolt, With Washer
|
901-19068-21-00 |
— | ||
| replacement | |||||
|
09
|
09
90119-06226-00 Bolt, With Washer |
90119-06226-00 |
from US $1.52 |
||
|
10
|
10
4JL-F1519-00-00
Mole, Fender
Ur black |
4JL-F1519-00-00 |
— | ||
|
11
|
11
977-07500-16-00
Screw, Tapping(4Mv)
|
977-07500-16-00 |
— | ||
| replacement | |||||
|
11
|
11
90167-05077-00 Screw, Tapping(4Tv) |
90167-05077-00 |
from US $2.08 |
||
