Front wheel Diagram Yamaha YL1/ YM1/ YM2
- Year
- 1967
- Sales region
- USA
- Engine Capacity
- 200
- Model
- YM2
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
152-25111-00-00
Hub, Front
|
152-25111-00-00 |
— | ||
|
2
|
2
152-25104-00-00
Spoke Set, Front
|
152-25104-00-00 |
— | ||
| replacement | |||||
|
2
|
2
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
3
|
3
156-25398-00-00
Balancer, Wheel (15G)
15G |
156-25398-00-00 |
— | ||
| replacement | |||||
|
3
|
3
3HT-25398-00-00 Balancer, Wheel (15G)15G |
3HT-25398-00-00 |
from US $8.08 |
||
|
4
|
4
94416-18013-00
Rim 1.60A X 18
1.60X18 |
94416-18013-00 |
— | ||
| replacement | |||||
|
4
|
4
999-99999-99-00
Not Available
1.60X18 |
999-99999-99-00 |
— | ||
|
5
|
5
94325-18043-00 Band, Rim (538)2.50-18 |
94325-18043-00 |
from US $4.39 |
||
| replacement | |||||
|
5
|
5
94340-18086-00 Band, Rim (2.50-18)2.50-18 |
94340-18086-00 |
from US $4.39 |
||
|
6
|
6
94230-18084-00 Tube (3.00-18) |
94230-18084-00 |
US $27.38 |
||
| replacement | |||||
|
6
|
6
94227-18195-00 Tube |
94227-18195-00 |
US $37.53 |
||
|
7
|
7
941-30180-38-00
Tire
|
941-30180-38-00 |
— | ||
|
7
|
7
941-30183-63-00
Yoko 300S18 Y986
300S18 Y986 |
941-30183-63-00 |
— | ||
|
8
|
8
152-25117-00-00
Spacer, Bearing
|
152-25117-00-00 |
— | ||
| replacement | |||||
|
8
|
8
90560-17291-00
Spacer
|
90560-17291-00 |
— | ||
|
9
|
9
146-25315-00-00 Flange, Spacer |
146-25315-00-00 |
from US $3.40 |
||
|
10
|
10
93306-20333-00 Bearing(39K) |
93306-20333-00 |
from US $15.30 |
||
| replacement | |||||
|
10
|
10
93306-20310-00 Bearing |
93306-20310-00 |
from US $15.30 |
||
|
11
|
11
931-05240-06-00
Oil Seal, Os-Type
|
931-05240-06-00 |
— | ||
|
12
|
12
931-07500-03-00
Oil Seal
|
931-07500-03-00 |
— | ||
|
13
|
13
152-25135-00-00
Gear, Drive
|
152-25135-00-00 |
— | ||
|
14
|
14
168-W2535-00-00
Brakeshoe Set-2Pcs
|
168-W2535-00-00 |
— | ||
|
14
|
14
4L0-W2536-00-00 Brake Shoe Kit |
4L0-W2536-00-00 |
from US $62.45 |
||
| replacement | |||||
|
14
|
14
5R3-W253E-00-00 Brake Shoe Kit |
5R3-W253E-00-00 |
from US $62.45 |
||
|
15
|
15
90507-20002-00 Spring, Tension 2462533300 |
90507-20002-00 |
from US $2 |
||
|
16
|
16
156-25121-01-00
Plate, Brake Shoe
|
156-25121-01-00 |
— | ||
|
16
|
16
157-25121-00-00
Plate, Brake Shoe
|
157-25121-00-00 |
— | ||
|
17
|
17
168-25151-00-00
Camshaft
|
168-25151-00-00 |
— | ||
|
18
|
18
148-25353-00-00 Shim, Camshaft |
148-25353-00-00 |
from US $2.98 |
||
|
19
|
19
148-25359-00-00 Seal, Camshaft |
148-25359-00-00 |
from US $2.69 |
||
|
20
|
20
905-08230-32-00
Spring, Torsion
|
905-08230-32-00 |
— | ||
|
21
|
21
168-25155-00-00
Lever, Camshaft 1
|
168-25155-00-00 |
— | ||
| replacement | |||||
|
21
|
21
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
22
|
22
97023-06020-00 Bolt |
97023-06020-00 |
from US $0.93 |
||
| replacement | |||||
|
22
|
22
970-24060-20-00 Bolt(3Dm) |
970-24060-20-00 |
from US $0.93 |
||
|
23
|
23
93700-06M03-00 Nipple, Grease |
93700-06M03-00 |
from US $2.66 |
||
|
24
|
24
152-25163-00-00 End, Rod 1 |
152-25163-00-00 |
US $40.01 |
||
|
25
|
25
90249-06095-00
Pin, Spec'l Shape
|
90249-06095-00 |
— | ||
| replacement | |||||
|
25
|
25
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
26
|
26
93430-04002-00 Circlip |
93430-04002-00 |
from US $1.56 |
||
| replacement | |||||
|
26
|
26
99080-04600-00 Circlip |
99080-04600-00 |
from US $1.34 |
||
|
27
|
27
953-80067-00-00 Nut |
953-80067-00-00 |
from US $1.34 |
||
| replacement | |||||
|
27
|
27
9538R-06700-00 Nut |
9538R-06700-00 |
from US $1.42 |
||
|
28
|
28
152-25161-00-00
Rod, Connecting
|
152-25161-00-00 |
— | ||
| replacement | |||||
|
28
|
28
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
29
|
29
152-25164-00-00 End, Rod 2 |
152-25164-00-00 |
from US $13.48 |
||
|
30
|
30
152-25125-00-00
Spring, Hook Pin
|
152-25125-00-00 |
— | ||
|
31
|
31
168-25156-00-00
Lever, Camshaft 2
|
168-25156-00-00 |
— | ||
|
32
|
32
970-11060-25-00
Bolt
|
970-11060-25-00 |
— | ||
| replacement | |||||
|
32
|
32
970-17060-25-00 Bolt |
970-17060-25-00 |
from US $1.34 |
||
|
33
|
33
929-95061-00-00 Washer, Spring |
929-95061-00-00 |
from US $0.99 |
||
|
34
|
34
97023-06020-00 Bolt |
97023-06020-00 |
from US $0.93 |
||
| replacement | |||||
|
34
|
34
970-24060-20-00 Bolt(3Dm) |
970-24060-20-00 |
from US $0.93 |
||
|
35
|
35
152-25138-00-00
Gear, Meter
|
152-25138-00-00 |
— | ||
|
36
|
36
109-25136-00-00 Bush |
109-25136-00-00 |
from US $10.71 |
||
|
37
|
37
93104-07003-00 Oil Seal, So-Type |
93104-07003-00 |
from US $1.84 |
||
|
38
|
38
932-10141-04-00
O-Ring
|
932-10141-04-00 |
— | ||
| replacement | |||||
|
38
|
38
93210-14579-00 O-Ring (26H) |
93210-14579-00 |
from US $1.28 |
||
|
39
|
39
903-87171-36-00
Collar
|
903-87171-36-00 |
— | ||
|
40
|
40
152-25181-00-00
Axle, Wheel
|
152-25181-00-00 |
— | ||
|
41
|
41
172-25126-00-00
Pin Pivot
|
172-25126-00-00 |
— | ||
|
42
|
42
95301-12700-00 Nut |
95301-12700-00 |
from US $2.13 |
||
| replacement | |||||
|
42
|
42
95317-12700-00 Nut, Hexagon Small |
95317-12700-00 |
from US $2.13 |
||
