Starter Diagram Yamaha YZ80
- Year
- 1978
- Sales region
- USA
- Engine Capacity
- 800
- Model
- YZ80
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
3AY-15620-00-00
Kick Crank Assembly
|
3AY-15620-00-00 |
— | ||
|
2
|
2
214-15612-09-00
Lever, Kick
|
214-15612-09-00 |
— | ||
|
3
|
3
90504-18031-00 Spring, Compression |
90504-18031-00 |
from US $3.05 |
||
|
4
|
4
90209-10108-00
Washer,spec'l Shape
|
90209-10108-00 |
— | ||
| replacement | |||||
|
4
|
4
902-09102-10-00
Washer (5L1)
|
902-09102-10-00 |
— | ||
|
5
|
5
934-40100-28-00
Circlip, Outer
|
934-40100-28-00 |
— | ||
|
6
|
6
156-15618-01-00 Cover, Kick Lever |
156-15618-01-00 |
from US $4.58 |
||
|
7
|
7
970-11060-25-00
Bolt
|
970-11060-25-00 |
— | ||
| replacement | |||||
|
7
|
7
970-17060-25-00 Bolt |
970-17060-25-00 |
from US $1.36 |
||
|
8
|
8
462-15660-00-00
Kick Axle Assembly
|
462-15660-00-00 |
— | ||
|
9
|
9
93109-15001-00 Oil Seal |
93109-15001-00 |
from US $4.43 |
||
|
10
|
10
99009-15400-00 Circlip(1Ar) |
99009-15400-00 |
from US $1.18 |
||
|
11
|
11
462-15676-00-00
Cover, Spring
|
462-15676-00-00 |
— | ||
|
12
|
12
90508-26196-00
Spring, Torsion (451-15665-00)
451-15665-00 |
90508-26196-00 |
— | ||
| replacement | |||||
|
12
|
12
999-99999-99-00
Not Available
451-15665-00 |
999-99999-99-00 |
— | ||
|
13
|
13
248-15668-00-00 Stopper |
248-15668-00-00 |
from US $2.70 |
||
|
14
|
14
462-15666-00-00
Spacer
|
462-15666-00-00 |
— | ||
|
14
|
14
2J5-15666-00-00
Spacer
|
2J5-15666-00-00 |
— | ||
|
15
|
15
93410-25017-00 Circlip |
93410-25017-00 |
from US $2.70 |
||
|
16
|
16
90201-253K0-00 Washer, Plate (T=1.0) |
90201-253K0-00 |
from US $1.81 |
||
|
17
|
17
90468-26038-00
Clip
|
90468-26038-00 |
— | ||
|
18
|
18
353-15641-00-00
Gear, Kick
24T |
353-15641-00-00 |
— | ||
