Steering Post And Tie Rod Diagram Arctic Cat 120 SNO PRO 120 Sno Pro
- Model code
- S2010ACAAAUSG
- Engine Capacity
- 123
- Year
- 2010
- Commercial Name
- 120 Sno Pro
- Sales region
- General
- Colour
- Green
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Model
- 120 Sno Pro
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
1705-313 PostSteering |
1705-313 |
US $111.85 |
||
|
2
|
2
1606-765 GripHandle |
1606-765 |
US $20.41 |
||
|
3
|
3
0302-165
Grip-right
|
0302-165 |
— | ||
|
4
|
4
1623-828 Pin |
1623-828 |
US $11.43 |
||
|
5
|
5
1623-882 PinSpring |
1623-882 |
US $15.45 |
||
|
6
|
6
0611-022 Stop switch decal |
0611-022 |
US $3.18 |
||
|
7
|
7
0109-609 Lever |
0109-609 |
US $19.09 |
||
|
8
|
8
0123-231 RingRetaining |
0123-231 |
US $9.50 |
||
|
9
|
9
0302-147 Grip-left |
0302-147 |
US $19.09 |
||
|
10
|
10
0609-007 SwitchStop |
0609-007 |
US $94.43 |
||
|
11
|
11
0605-560 CoverHandlebar pad |
0605-560 |
US $26.64 |
||
|
12
|
12
0605-501 PadHandlebar |
0605-501 |
US $29.71 |
||
|
13
|
13
1623-861 ScrewCap |
1623-861 |
US $7.24 |
||
| replacement | |||||
|
13
|
13
8020-040 ScrewCap |
8020-040 |
US $26.60 |
||
|
14
|
14
0705-896 RetainerBearing |
0705-896 |
US $16.80 |
||
|
15
|
15
0605-444 BearingSteering post |
0605-444 |
US $4.70 |
||
|
16
|
16
1623-868 NutLock |
1623-868 |
US $3.70 |
||
| replacement | |||||
|
16
|
16
8047-366 NutLock |
8047-366 |
US $5.80 |
||
|
17
|
17
1623-423 NutLock |
1623-423 |
US $19.60 |
||
|
18
|
18
1623-874 Washer |
1623-874 |
US $11.80 |
||
| replacement | |||||
|
18
|
18
8050-247 Washer |
8050-247 |
US $8.80 |
||
|
19
|
19
8004-135 ScrewCap |
8004-135 |
US $8.25 |
||
|
20
|
20
1703-853 Tie rodAssembly inc. 21-24 ; |
1703-853 |
US $107.89 |
||
|
21
|
21
0605-777
Rod end
|
0605-777 |
— | ||
|
22
|
22
0623-260 NutL.h. thds.; jam |
0623-260 |
US $5.45 |
||
|
23
|
23
0123-144 NutJam |
0123-144 |
US $0.22 |
||
|
24
|
24
0605-776
Rod end
|
0605-776 |
— | ||
|
25
|
25
8060-504 Rivet |
8060-504 |
US $8.60 |
||
|
26
|
26
1707-444 SupportSteering post |
1707-444 |
US $72.28 |
||
|
27
|
27
0630-266 SwitchAssembly; tether inc. 28 ; |
0630-266 |
US $68.17 |
||
| replacement | |||||
|
27
|
27
0630-138 SwitchInc. 18; assembly; tether inc. 28 ; |
0630-138 |
US $68.17 |
||
|
28
|
28
0630-139 CordTether switch |
0630-139 |
US $47.08 |
||
|
29
|
29
0687-229 CableBrake |
0687-229 |
US $53.28 |
||
|
30
|
30
1602-100 SpringBrake; return |
1602-100 |
US $11.43 |
||
|
31
|
31
0687-221 CableThrottle inc. two No. 32 ; |
0687-221 |
US $49.78 |
||
| replacement | |||||
|
31
|
31
0687-231 Cable,throttle(120)inc. two No. 32 ; |
0687-231 |
US $42.11 |
||
|
32
|
32
8053-212 WasherLock |
8053-212 |
US $1.45 |
||
|
33
|
33
0123-788 TieCable |
0123-788 |
US $2.90 |
||
