Belt Guard Assembly Diagram Arctic Cat BEARCAT Bearcat 660 Wide Track
- Model code
- S2004BCFWTUSS
- Engine Capacity
- 658
- Year
- 2004
- Commercial Name
- Bearcat 660 Wide Track
- Sales region
- General
- Power
- 53 hp
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- Model
- Bearcat 660 Wide Track
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
0707-574 Belt guardinc. 2-5 and one No. 6 ; |
0707-574 |
US $97.14 |
||
|
2
|
2
0607-549 BushingBelt guard |
0607-549 |
US $3.09 |
||
|
3
|
3
0607-550 PlateBelt guard; bushing |
0607-550 |
US $11.10 |
||
|
4
|
4
8060-504 Rivet |
8060-504 |
US $8.60 |
||
|
5
|
5
0607-447 Cable |
0607-447 |
US $4.98 |
||
|
6
|
6
0605-283 KeyCotter |
0605-283 |
US $14.25 |
||
|
7
|
7
5611-553 DecalClutching |
5611-553 |
US $29.86 |
||
|
8
|
8
1611-565 PlateSwitches; console |
1611-565 |
US $1.92 |
||
|
9
|
9
3611-969 DecalRoller driven clutch"; "act |
3611-969 |
US $90.04 |
||
|
10
|
10
1623-012 PinBelt guard |
1623-012 |
US $17.09 |
||
|
11
|
11
0607-094 InsertHinge |
0607-094 |
US $1.34 |
||
|
12
|
12
0707-797 BracketBelt guard; mounting |
0707-797 |
US $20.44 |
||
|
13
|
13
8061-508 Rivet |
8061-508 |
US $19 |
