Instrument panel Diagram Yamaha EC340 Excel III
- Model code
- EC340
- Engine Capacity
- 340
- Year
- 1981
- Sales region
- USA
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
8L6-77711-00-00
Panel, Instrument
|
8L6-77711-00-00 |
— | ||
|
2
|
2
8J9-77741-00-00
Indicator 1
|
8J9-77741-00-00 |
— | ||
|
3
|
3
8A1-77743-00-00
Indicator 3
|
8A1-77743-00-00 |
— | ||
| replacement | |||||
|
3
|
3
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
4
|
4
878-77744-00-00
Indicator 4
|
878-77744-00-00 |
— | ||
| replacement | |||||
|
4
|
4
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
5
|
5
878-77745-00-00
Indicator 5
|
878-77745-00-00 |
— | ||
| replacement | |||||
|
5
|
5
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
6
|
6
8G8-77742-00-00
Indicator 2
|
8G8-77742-00-00 |
— | ||
|
7
|
7
8E7-77742-00-00
Indicator 2
|
8E7-77742-00-00 |
— | ||
|
8
|
8
8G8-77767-01-00
Label, Warning 7
|
8G8-77767-01-00 |
— | ||
|
9
|
9
98506-06014-00 Screw Pan Head |
98506-06014-00 |
from US $1.07 |
||
| replacement | |||||
|
9
|
9
98507-06014-00 Screw, Pan Head |
98507-06014-00 |
from US $1.07 |
||
|
10
|
10
90201-06057-00 Washer, Plate |
90201-06057-00 |
from US $1.28 |
||
|
11
|
11
929-06061-00-00
Washer, Spring
|
929-06061-00-00 |
— | ||
| replacement | |||||
|
11
|
11
92907-06100-00 Washer, Spring |
92907-06100-00 |
from US $0.93 |
||
|
12
|
12
8G8-77746-00-00
Grommet
|
8G8-77746-00-00 |
— | ||
|
13
|
13
341-26397-01-00
Band
|
341-26397-01-00 |
— | ||
| replacements | |||||
|
13
|
13
437-83936-01-00 Band, Switch Cord |
437-83936-01-00 |
from US $1.56 |
||
|
13
|
13
437-83936-11-00 Band, Switch Cord |
437-83936-11-00 |
from US $1.56 |
||
