Torque converter Diagram Yamaha EW643
- Model code
- EW643
- Engine Capacity
- 643
- Year
- 1973
- Sales region
- USA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
99009-52500-00 Circlip |
99009-52500-00 |
from US $4.96 |
||
|
1
|
1
852-16700-00-00
Torque Conv Assembly
|
852-16700-00-00 |
— | ||
|
2
|
2
933-06205-29-00 Bearing |
933-06205-29-00 |
from US $16.20 |
||
|
3
|
3
934-40250-84-00 Circlip |
934-40250-84-00 |
from US $1.70 |
||
|
4
|
4
931-03250-69-00 Oil Seal, Sw-Type |
931-03250-69-00 |
from US $13.03 |
||
| replacement | |||||
|
4
|
4
931-03251-25-00 Oil Seal, Sw-Type |
931-03251-25-00 |
from US $13.03 |
||
|
5
|
5
931-03480-70-00 Oil Seal, Sw-Type |
931-03480-70-00 |
US $29.39 |
||
|
6
|
6
933-06007-03-00
Bearing
|
933-06007-03-00 |
— | ||
|
7
|
7
834-16715-00-00
Shim
|
834-16715-00-00 |
— | ||
|
8
|
8
93410-35027-00
Circlip, S-Type (S-35)
|
93410-35027-00 |
— | ||
|
9
|
9
932-10692-03-00
O-Ring
|
932-10692-03-00 |
— | ||
|
10
|
10
932-11781-69-00
O-Ring
|
932-11781-69-00 |
— | ||
|
11
|
11
834-16737-00-00
Bearing, Thrust
|
834-16737-00-00 |
— | ||
|
12
|
12
934-10280-28-00
Circlip, S-Type
|
934-10280-28-00 |
— | ||
|
13
|
13
93306-20111-00 Bearing |
93306-20111-00 |
from US $20.12 |
||
| replacement | |||||
|
13
|
13
933-06201-19-00 Bearing |
933-06201-19-00 |
from US $11.58 |
||
|
14
|
14
92990-10100-00 Ybs67-10 Washer, Spring |
92990-10100-00 |
from US $1.34 |
||
|
15
|
15
95303-10700-00 Nut |
95303-10700-00 |
US $7.37 |
||
| replacement | |||||
|
15
|
15
95380-10700-00 Nut |
95380-10700-00 |
from US $7.37 |
||
|
16
|
16
985-11050-18-00
Screw, Pan Head
|
985-11050-18-00 |
— | ||
|
17
|
17
92990-05100-00 Washer, Spring |
92990-05100-00 |
from US $1.21 |
||
|
18
|
18
90105-08003-00 Bolt, Flange |
90105-08003-00 |
from US $4.82 |
||
| replacement | |||||
|
18
|
18
90105-08729-00 Bolt, Washer Based |
90105-08729-00 |
from US $4.82 |
||
|
19
|
19
90430-08023-00
Gasket
|
90430-08023-00 |
— | ||
| replacement | |||||
|
19
|
19
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
20
|
20
834-16756-00-00
Connector, Pipe
|
834-16756-00-00 |
— | ||
|
21
|
21
214-11198-01-00 Washer-gasket |
214-11198-01-00 |
from US $1.66 |
||
|
22
|
22
932-11131-09-00
O-Ring
|
932-11131-09-00 |
— | ||
|
23
|
23
93604-18058-00
Pin, Dowel
|
93604-18058-00 |
— | ||
| replacement | |||||
|
23
|
23
93604-18251-00
Pin, Dowel(4Ss)
|
93604-18251-00 |
— | ||
|
24
|
24
834-17641-00-00
V-Belt
|
834-17641-00-00 |
— | ||
|
25
|
25
852-16785-02-00
Pulley 1
|
852-16785-02-00 |
— | ||
|
26
|
26
90170-16182-00 Nut |
90170-16182-00 |
from US $3.12 |
||
| replacement | |||||
|
26
|
26
90170-16425-00 Nut |
90170-16425-00 |
from US $3.12 |
||
|
27
|
27
902-08160-14-00
Washer, Conical Spr
|
902-08160-14-00 |
— | ||
|
28
|
28
905-60170-78-00
Spacer
|
905-60170-78-00 |
— | ||
