Brake Diagram Yamaha EX570 Exciter II
- Model code
- 8BA1
- Engine Capacity
- 569
- Year
- 1993
- Sales region
- Europe (General) (999)
- Model
- Exciter II
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
87M-25831-00-00 Disc, Brake (Right) |
87M-25831-00-00 |
US $205.99 |
||
| replacement | |||||
|
01
|
01
87M-25831-01-00 Disc, Brake (Right) |
87M-25831-01-00 |
US $191.16 |
||
|
02
|
02
8J7-25848-00-00 Key |
8J7-25848-00-00 |
from US $6.09 |
||
|
03
|
03
86V-25730-00-00
Caliper Body Comp.1
|
86V-25730-00-00 |
— | ||
|
04
|
04
86M-25738-00-00 Screw, Adjusting 1 |
86M-25738-00-00 |
from US $7.37 |
||
|
05
|
05
86P-25726-21-00
Lever, Brake
|
86P-25726-21-00 |
— | ||
|
06
|
06
86M-25827-00-00 Shim, Caliper |
86M-25827-00-00 |
from US $1.56 |
||
|
07
|
07
86P-25773-00-00
Lock, one way 2
|
86P-25773-00-00 |
— | ||
|
08
|
08
86M-25771-00-00 Ratchet, Adjusting |
86M-25771-00-00 |
from US $4.82 |
||
|
09
|
09
86V-25772-00-00
Cover, End
|
86V-25772-00-00 |
— | ||
|
10
|
10
86M-25818-00-00 Bolt, Caliper |
86M-25818-00-00 |
from US $3.68 |
||
|
11
|
11
86P-25721-20-00
Stopper, Cable
|
86P-25721-20-00 |
— | ||
|
12
|
12
86P-25826-20-00
Bolt 3
|
86P-25826-20-00 |
— | ||
|
13
|
13
86P-25743-20-00
Spring
|
86P-25743-20-00 |
— | ||
|
14
|
14
86P-25828-20-00
Shim, Caliper
|
86P-25828-20-00 |
— | ||
|
15
|
15
86M-25736-00-00
Hook, spring
|
86M-25736-00-00 |
— | ||
|
16
|
16
86M-25833-00-00 Bolt, Fitting |
86M-25833-00-00 |
from US $1.56 |
||
|
17
|
17
86M-25744-00-00 Pin 2 |
86M-25744-00-00 |
from US $1.56 |
||
|
18
|
18
95811-10050-00 Bolt, Flange (5X5) |
95811-10050-00 |
from US $2.55 |
||
| replacement | |||||
|
18
|
18
95817-10050-00 Bolt, Flange |
95817-10050-00 |
from US $2.55 |
||
|
19
|
19
89J-25811-00-00 Pad, Caliper 2 |
89J-25811-00-00 |
from US $29.32 |
||
|
20
|
20
89J-25911-00-00 Pad, Caliper 2 |
89J-25911-00-00 |
from US $38.13 |
||
