Control cable Diagram Yamaha FX10/ RFX10 FX Nytro
- Model code
- 8JH2
- Engine Capacity
- 1049
- Year
- 2014
- Sales region
- USA
- Power
- 130 hp
- Model
- FX Nytro
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
8GL-26311-00-00 Cable, Throttle 1 |
8GL-26311-00-00 |
from US $54.99 |
||
|
2
|
2
8HR-26241-01-00 Grip |
8HR-26241-01-00 |
from US $13.88 |
||
|
3
|
3
8JH-2626A-00-00 Grip, Warmer |
8JH-2626A-00-00 |
from US $64.66 |
||
|
4
|
4
8JH-2626A-10-00 Grip, Warmer |
8JH-2626A-10-00 |
from US $64.66 |
||
|
5
|
5
90267-48014-00 Rivet, Blind4.8X15.1 BLACK |
90267-48014-00 |
from US $1.70 |
||
|
6
|
6
8GL-2612L-01-00 Bracket 3 |
8GL-2612L-01-00 |
from US $33.86 |
||
|
7
|
7
8GL-2612M-01-00 Bracket 4 |
8GL-2612M-01-00 |
from US $33.86 |
||
|
8
|
8
8GL-2612K-00-00 Bracket 2 |
8GL-2612K-00-00 |
from US $10.63 |
||
|
9
|
9
90109-065F3-00 Bolt |
90109-065F3-00 |
from US $1.84 |
||
|
10
|
10
91312-05030-00 Bolt |
91312-05030-00 |
from US $1.42 |
||
|
11
|
11
8GL-F6141-30-00 Guard, Brush 1 |
8GL-F6141-30-00 |
from US $10.51 |
||
|
12
|
12
8GL-F6142-30-00 Guard, Brush 2 |
8GL-F6142-30-00 |
from US $9.49 |
