Bumper Diagram Yamaha FX10/ RFX10 FX Nytro M-TX 162 SE
- Model code
- 8HR3
- Engine Capacity
- 1049
- Year
- 2011
- Sales region
- USA
- Power
- 130 hp
- Model
- FX Nytro M-TX SE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
8GL-77511-00-00 Bumper, Front 1 |
8GL-77511-00-00 |
from US $172.70 |
||
|
2
|
2
95812-08020-00 Bolt, Flange |
95812-08020-00 |
from US $1.34 |
||
|
3
|
3
8HR-77541-00-00 Bumper, Rear 1 |
8HR-77541-00-00 |
from US $258.36 |
||
|
4
|
4
95812-08020-00 Bolt, Flange |
95812-08020-00 |
from US $1.34 |
||
|
5
|
5
90338-21145-00 Plug |
90338-21145-00 |
from US $6.80 |
||
|
6
|
6
90267-47200-00 Rivet, Blind (4.7X19.5 Black)4.7X19.5 BLACK |
90267-47200-00 |
from US $1.98 |
||
|
7
|
7
8GL-21731-00-00 Cover, Side 3 |
8GL-21731-00-00 |
from US $43.93 |
||
|
8
|
8
8GL-21741-00-00 Cover, Side 4 |
8GL-21741-00-00 |
from US $43.93 |
||
|
9
|
9
902-69080-06-00 Rivet |
902-69080-06-00 |
from US $2.55 |
||
|
10
|
10
8GL-24756-00-00 Cover, Tail |
8GL-24756-00-00 |
from US $33.58 |
||
|
11
|
11
90154-06009-00 Screw, Binding |
90154-06009-00 |
from US $2.69 |
||
|
12
|
12
8GL-84516-00-00 Cover, Taillight |
8GL-84516-00-00 |
from US $9.07 |
||
|
13
|
13
8FS-84544-00-00 Cover |
8FS-84544-00-00 |
from US $8.36 |
||
|
14
|
14
90109-06174-00 Bolt |
90109-06174-00 |
from US $1.98 |
||
|
15
|
15
8GL-77551-00-00 Protector 1 |
8GL-77551-00-00 |
from US $35.56 |
||
|
16
|
16
8GL-77552-00-00 Protector 2 |
8GL-77552-00-00 |
from US $35.56 |
||
|
17
|
17
8GL-77553-00-00 Protector 3 |
8GL-77553-00-00 |
from US $5.95 |
||
|
18
|
18
8GL-77554-00-00 Protector 4 |
8GL-77554-00-00 |
from US $5.95 |
||
|
19
|
19
8GL-77555-00-00 Protector 5 |
8GL-77555-00-00 |
from US $1.21 |
||
|
20
|
20
8GL-77555-10-00 Protector 5 |
8GL-77555-10-00 |
from US $1.21 |
||
|
21
|
21
8GL-77556-00-00 Protector 6 |
8GL-77556-00-00 |
from US $38.82 |
||
|
22
|
22
8GL-77557-00-00 Protector 7 |
8GL-77557-00-00 |
from US $1.21 |
||
|
23
|
23
8GL-7717E-00-00 Tape 1 |
8GL-7717E-00-00 |
from US $1.21 |
||
|
24
|
24
8GL-77261-00-00 Lining, Shroud 1 |
8GL-77261-00-00 |
from US $1.21 |
||
|
25
|
25
8GT-K7595-00-00 Flap |
8GT-K7595-00-00 |
from US $59.26 |
