Instrument panel Diagram Yamaha PZ50/ RPZ50 Venture Lite
- Model code
- 8GJ7
- Engine Capacity
- 499
- Year
- 2010
- Sales region
- USA
- Power
- 80 hp
- Model
- Venture Lite
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
8GJ-77711-00-P2 Panel, Instrumentfor Color Deep Red Metallic K DRMK / 0918 |
8GJ-77711-00-P2 |
from US $280.46 |
||
|
1
|
1
8GJ-77711-00-P4 Panel, Instrumentfor Color PURPLISH BLUE METALLIC 7 PBM7 / 0549 |
8GJ-77711-00-P4 |
from US $280.46 |
||
|
2
|
2
8FP-77746-01-00 Grommet |
8FP-77746-01-00 |
from US $8.50 |
||
|
3
|
3
90183-06069-00 Nut, Spring |
90183-06069-00 |
from US $3.54 |
||
|
4
|
4
90109-06220-00 Bolt |
90109-06220-00 |
from US $1.84 |
||
|
5
|
5
5YU-2411B-01-00 Emblem |
5YU-2411B-01-00 |
from US $29.61 |
||
|
6
|
6
8GJ-21711-20-00 Cover, Side 1 |
8GJ-21711-20-00 |
from US $53.61 |
||
|
7
|
7
8GJ-21721-20-00 Cover, Side 2 |
8GJ-21721-20-00 |
from US $53.61 |
||
|
8
|
8
4XV-2177L-01-00 Plate, Spring |
4XV-2177L-01-00 |
from US $7.23 |
||
|
9
|
9
90109-06220-00 Bolt |
90109-06220-00 |
from US $1.84 |
||
|
10
|
10
90338-04208-00 Plug |
90338-04208-00 |
from US $3.10 |
||
|
11
|
11
8GC-2415E-E0-00 Label, Caution |
8GC-2415E-E0-00 |
from US $1.28 |
||
|
12
|
12
8ET-2815K-00-00 Label, Notice Windshield 1 |
8ET-2815K-00-00 |
from US $2.55 |
||
|
13
|
13
8ET-2815K-10-00 Label, Notice Windshield 1 |
8ET-2815K-10-00 |
from US $2.69 |
