Windshield Diagram Yamaha RS10/RS90/RST90/RSG90 RS Vector Mountain SE
- Model code
- 8GE4
- Engine Capacity
- 1000
- Year
- 2007
- Sales region
- Japan (020)
- Colour
- Yamaha Black (YB; 0033)
- Power
- 120 hp
- Model
- RS Vector Mountain SE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
8FA-77251-01-00 Cover, Headlight |
8FA-77251-01-00 |
from US $93.35 |
||
|
02
|
02
8FA-77185-00-00 Plate 1 |
8FA-77185-00-00 |
from US $24.24 |
||
|
03
|
03
8FA-77186-00-00 Plate 2 |
8FA-77186-00-00 |
from US $24.24 |
||
|
04
|
04
977-07500-16-00
Screw, Tapping(4Mv)
|
977-07500-16-00 |
— | ||
| replacement | |||||
|
04
|
04
90167-05077-00 Screw, Tapping(4Tv) |
90167-05077-00 |
from US $1.65 |
||
|
05
|
05
98907-06014-00 Screw, Binding |
98907-06014-00 |
from US $1.50 |
||
|
06
|
06
8GE-772A0-00-00 Windscreen Comp |
8GE-772A0-00-00 |
US $224.96 |
||
|
07
|
07
8FY-77213-00-00 Trim, Upper |
8FY-77213-00-00 |
US $21.24 |
||
|
08
|
08
901-50050-24-00 Screw, Round Head |
901-50050-24-00 |
from US $1.50 |
||
|
09
|
09
901-79055-23-00 Nut |
901-79055-23-00 |
from US $2.99 |
||
|
10
|
10
8FA-77231-A0-P2 FairingDrmk |
8FA-77231-A0-P2 |
US $231.08 |
||
|
11
|
11
90183-06053-00 Nut, Spring |
90183-06053-00 |
from US $3.29 |
||
| replacement | |||||
|
11
|
11
90183-06069-00 Nut, Spring |
90183-06069-00 |
from US $3.29 |
||
|
12
|
12
90154-06009-00 Screw, Binding |
90154-06009-00 |
from US $2.39 |
||
|
13
|
13
8FA-77214-00-00 Trim, Lower |
8FA-77214-00-00 |
from US $1.94 |
||
|
14
|
14
8FA-77215-00-00 Trim 3 |
8FA-77215-00-00 |
from US $1.05 |
||
|
15
|
15
80V-2835Y-90-00 Caution Label 1For jpn |
80V-2835Y-90-00 |
from US $2.94 |
||
|
16
|
16
90183-06053-00 Nut, Spring |
90183-06053-00 |
from US $3.29 |
||
| replacement | |||||
|
16
|
16
90183-06069-00 Nut, Spring |
90183-06069-00 |
from US $3.29 |
||
