Electrical 3 Diagram Yamaha RS10/RS90/RST90/RSG90 RS Vector L-TX
- Model code
- 8HW7
- Engine Capacity
- 1000
- Year
- 2015
- Sales region
- USA
- Model
- RS Vector L-TX
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
3Y6-85130-02-00 Reflector |
3Y6-85130-02-00 |
from US $10.58 |
||
|
2
|
2
95702-05500-00 Nut, With Washer |
95702-05500-00 |
from US $0.50 |
||
| replacement | |||||
|
2
|
2
95707-05500-00 Nut, Flange |
95707-05500-00 |
from US $1.07 |
||
|
3
|
3
8GM-85110-00-00 Reflector Assy |
8GM-85110-00-00 |
from US $9.35 |
||
|
4
|
4
95702-05500-00 Nut, With Washer |
95702-05500-00 |
from US $0.50 |
||
| replacement | |||||
|
4
|
4
95707-05500-00 Nut, Flange |
95707-05500-00 |
from US $1.07 |
||
|
5
|
5
8FR-77421-00-00 Bracket 1 |
8FR-77421-00-00 |
from US $5.53 |
||
|
6
|
6
8FR-77422-00-00 Bracket 2 |
8FR-77422-00-00 |
from US $5.38 |
||
|
7
|
7
90267-48104-00 Rivet, Blind (4.8X12.4 Black) |
90267-48104-00 |
from US $2.55 |
||
