Instrument panel Diagram Yamaha RS10/RS90/RST90/RSG90 RS Venture GT
- Model code
- 8HF5
- Engine Capacity
- 1000
- Year
- 2011
- Sales region
- USA
- Power
- 120 hp
- Model
- RS Venture GT
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
8FP-77711-00-33 Panel, Instrumentfor Color YAMAHA BLACK YB / 0033 |
8FP-77711-00-33 |
from US $205.86 |
||
|
1
|
1
8FP-77711-00-P6 Panel, InstrumentUR FOR VPBC5 |
8FP-77711-00-P6 |
US $333.81 |
||
|
2
|
2
8FP-77746-01-00 Grommet |
8FP-77746-01-00 |
from US $8.50 |
||
|
3
|
3
4XV-2177L-01-00 Plate, Spring |
4XV-2177L-01-00 |
from US $7.23 |
||
|
4
|
4
90154-06009-00 Screw, Binding |
90154-06009-00 |
from US $2.69 |
||
|
5
|
5
90109-06220-00 Bolt |
90109-06220-00 |
from US $1.84 |
||
|
6
|
6
5PW-2177L-00-00
Plate, Spring
|
5PW-2177L-00-00 |
— | ||
| replacement | |||||
|
6
|
6
5PW-2177L-01-00 Plate, Spring |
5PW-2177L-01-00 |
from US $7.23 |
||
|
7
|
7
8HF-77712-00-P2 Panel, InstrumentUR FOR VPBC5 |
8HF-77712-00-P2 |
US $153.23 |
||
|
7
|
7
8HF-77712-00-33 Panel, Instrumentfor Color YAMAHA BLACK YB / 0033 |
8HF-77712-00-33 |
US $165.83 |
||
|
8
|
8
5PW-28386-00-00 Head |
5PW-28386-00-00 |
from US $12.89 |
||
|
9
|
9
2TK-21757-00-00 Washer, Special 1 |
2TK-21757-00-00 |
from US $2.13 |
||
|
10
|
10
8FP-21711-00-00 Cover, Side 1 |
8FP-21711-00-00 |
from US $29.89 |
||
|
11
|
11
8FP-21721-00-00 Cover, Side 2 |
8FP-21721-00-00 |
from US $29.89 |
||
|
12
|
12
8FR-7717F-00-00 Tape 2 |
8FR-7717F-00-00 |
from US $2.83 |
||
|
13
|
13
8FR-77151-00-00 Pad 1 |
8FR-77151-00-00 |
from US $2.27 |
||
|
14
|
14
90149-06117-00 Screw |
90149-06117-00 |
from US $1.70 |
||
|
15
|
15
90154-06009-00 Screw, Binding |
90154-06009-00 |
from US $2.69 |
||
