Instrument panel Diagram Yamaha SR10/ SRV10 SR Viper M-TX 162 LE
- Model code
- 8KU1
- Engine Capacity
- 1049
- Year
- 2015
- Sales region
- USA
- Power
- 135 hp
- Model
- SR Viper M-TX 162 LE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
8JP-K7712-00-00 Panel, Instrument |
8JP-K7712-00-00 |
US $225.63 |
||
|
2
|
2
8JM-RA201-00-00 Screw, Tapping 10-12X5/810-12X5/8 |
8JM-RA201-00-00 |
US $12.25 |
||
| replacement | |||||
|
2
|
2
8KC-RA290-00-00 SCREW, 10-12X3/410-12X5/8 |
8KC-RA290-00-00 |
US $12.70 |
||
|
3
|
3
8KG-K7131-00-00 Louver 1 |
8KG-K7131-00-00 |
US $37.21 |
||
|
4
|
4
8JP-RA253-00-00 Screw, M6-1.0X18M6-1.0X18 |
8JP-RA253-00-00 |
US $10.36 |
||
|
5
|
5
8KG-K7711-20-00 Panel, Instrument |
8KG-K7711-20-00 |
US $97.15 |
||
|
6
|
6
8JP-RA252-00-00 Screw, M6-1.0X15M6-1.0X15 |
8JP-RA252-00-00 |
US $7.38 |
||
|
7
|
7
8JP-K6169-00-00 Nut |
8JP-K6169-00-00 |
US $3.46 |
||
|
8
|
8
8JP-RA352-00-00 Nut, Clip 1010 |
8JP-RA352-00-00 |
US $4.36 |
||
|
9
|
9
8JP-K7713-00-00 Panel, Instrument |
8JP-K7713-00-00 |
US $226.75 |
||
|
10
|
10
8JP-K7761-70-00 Label, Warning 1 |
8JP-K7761-70-00 |
US $15.98 |
||
|
11
|
11
8JP-K7761-S0-00 Label, Warning 1 |
8JP-K7761-S0-00 |
US $14.63 |
||
|
12
|
12
8JP-K7561-00-00 Protector, Side 1 |
8JP-K7561-00-00 |
US $11.79 |
||
| replacement | |||||
|
12
|
12
8JP-K7561-01-00 Protector, Side |
8JP-K7561-01-00 |
US $12.56 |
||
|
13
|
13
8JP-R4261-00-00 Velcro (6.5 Feet)6.5 FEET UN |
8JP-R4261-00-00 |
US $36.77 |
||
|
14
|
14
8JP-RA345-00-00 Nut, 1 |
8JP-RA345-00-00 |
US $7.49 |
||
|
15
|
15
8JP-RAK02-00-00 Pin, 2 |
8JP-RAK02-00-00 |
US $26.01 |
||
